www. ks termi na l s . com The Foundation of Reliable Power for Data Centers Professional Grade DUAL-HOLE COPPER LUGS Featuring a dual-hole configuration, this design prevents terminal rotation caused by vibration or heavy cable tension. It ensures maximum surface contact and guarantees the absolute stability of power transmission. In addition to our standard high-quality tin plating, we offer customizable nickel-plated options for specific models. Designed for extreme temperatures or highly corrosive environments, it significantly enhances oxidation resistance and durability to extend equipment life. K. S. TERMINALS INC. Excellence in connector solution
K. S. TERMINALS INC. W T 2xd2 L A E D d1 W T A 2xd2 E 45 d1 D ° TCLH-2A Series TCLH-2A-45D Series TCLH-2A-90D Series A W 2xd2 T 90 E d1 D ° WIRE RANGE A.W.G. 2 mm ITEM NO. STUD SIZE 2*d2 W L E A d1 D T DIMENSION mm (inch) ANGLE 4 A.W.G. 2 25 mm TCLH10-2B5-00 TCLH16-2B6 TCLH16-4-2A TCLH16-5-2A TCLH16-6-2A TCLH16-6-2AS 5 (0.2) 8 A.W.G. 2 10 mm 6 A.W.G. 2 16 mm TCLH10-5-2A TCLH10-6-2A 9.9 (0.39) 14.0 (0.55) 45.9 (1.81) 9.32 (0.37) 4.8 (0.19) 6.6 (0.26) 1.6 (0.063) 180 5.3 (0.21) 10.4 (0.41) 14.25 (0.56) 47.5 (1.87) 16.0 (0.63) 4.5 (0.18) 6.9 (0.27) 2.0 (0.079) 6.4 (0.25) 10.4 (0.41) 14.25 (0.56) 47.5 (1.87) 16.0 (0.63) 4.5 (0.18) 6.9 (0.27) 2.0 (0.079) 4.3 (0.17) 12.2 (0.48) 20.5 (0.81) 56.0 (2.2) 19.0 (0.75) 5.5 (0.22) 7.9 (0.31) 2.0 (0.079) 180 5.3 (0.21) 12.2 (0.48) 20.5 (0.81) 56.0 (2.2) 16.0 (0.63) 5.5 (0.22) 7.9 (0.31) 2.0 (0.079) 180 6.4 (0.25) 12.2 (0.48) 20.5 (0.81) 56.0 (2.2) 16.0 (0.63) 5.5 (0.22) 7.9 (0.31) 2.0 (0.079) 180 TCLH16-6-2A-45D 6.4 (0.25) 12.2 (0.48) 20.5 (0.81) 50.8 (2.0) 16.0 (0.63) 5.5 (0.22) 7.9 (0.31) 2.0 (0.079) 45 6.4 (0.25) 12.2 (0.48) 16.5 (0.65) 52.0 (2.05) 16.0 (0.63) 180 5.5 (0.22) 7.9 (0.31) 2.0 (0.079) 6.5 (0.26) 12.2 (0.48) 20.5 (0.81) 66.3 (2.61) 25.4 (1.0) 5.5 (0.22) 7.9 (0.31) 2.0 (0.079) 180 TCLH25-2A6-45D 6.5 (0.26) 13.1 (0.52) 16.0 (0.63) - 15.9 (0.63) 6.7 (0.26) 9.1 (0.36) 2.4 (0.094) 45 TCLH25-2B6 6.5 (0.26) 14.0 (0.55) 20.6 (0.81) 66.8 (2.63) 25.4 (1.0) 7.1 (0.28) 9.7 (0.38) 2.3 (0.091) 180 TCLH25-2A6.5-45D 6.9 (0.27) 13.1 (0.52) 16.0 (0.63) - 15.9 (0.63) 6.7 (0.26) 9.1 (0.36) 2.4 (0.094) 45 TCLH25-2A6.5 6.9 (0.27) 13.1 (0.52) 16.0 (0.63) 51.6 (2.03) 15.9 (0.63) 6.7 (0.26) 9.1 (0.36) 2.4 (0.094) 180 2 A.W.G. 2 35 mm TCLH35-2A6.5 6.9 (0.27) 17.0 (0.67) 23.0 (0.91) 65.4 (2.57) 15.9 (0.63) 9.1 (0.36) 11.9 (0.47) 2.8 (0.11) 180 TCLH35-2B6.5 6.9 (0.27) 17.0 (0.67) 23.0 (0.91) 74.9 (2.95) 25.4 (1.0) 9.1 (0.36) 11.9 (0.47) 2.8 (0.11) 180 TCLH35-2B6.5-90D 6.9 (0.27) 17.0 (0.67) 23.0 (0.91) 56.4 (2.22) 25.4 (1.0) 9.1 (0.36) 11.9 (0.47) 2.8 (0.11) 90 1/0 A.W.G. 2 50 mm 180 TCLH50-6-2A 6.4 (0.25) 19.0 (0.75) 24.5 (0.96) 68.6 (2.7) 19.0 (0.75) 10.0 (0.39) 13.2 (0.52) 3.2 (0.126) TCLH25-2A6 6.5 (0.26) 13.1 (0.52) 16.0 (0.63) 15.9 (0.63) 6.7 (0.26) 9.1 (0.36) 2.4 (0.094) 51.6 (2.03) 180 Panduit Equivalent 180 180 LCD8-10A-L - LCD8-14A-L LCD6-14D-L - LCD6-10A-L LCD6-14A-L LCD6-14AH-L LCD6-14A-L LCD4-14D-L LCD4-14AH-L LCD4-14AH-L LCD4-14A-L LCD4-14D-L LCD2-14A-Q LCD2-14D-Q LCD1/0-14B-X LCD2-14DF-Q TERMINAL MATERIAL: COPPER TUBULAR A.W.G. AMP. 8 70 6 95 4 125 2 170 1/0 230 MAXIMUM ELECTRIC CURRENT: : NOT UL AND C-UL LISTED ALL LISTED
