DIN TERMINALS THE STANDARD OF RELIABILITY IN EVERY CRIMP PRECISION ELECTRICAL SOLUTIONS 2026 PRODUCT CATALOG DURABLE High quality components built for strength and long service life. EFFICIENT Optimized performance for demanding applications. RELIABLE Engineered for safe and secure connections.
1 - 6 INDEX A.DIN TERMINALS 2.NON-INSULATED TERMINALS (NB SERIES) EXAMPLE FOR YOUR ORDER DESCRIPTION 1 INDEX K. S. TERMINALS INC. NON-INSULATED DIN 46230 PIN TERMINALS NON-INSULATED DIN 46234 RING TERMINALS NON-INSULATED DIN 46234 SPADE TERMINALS NON-INSULATED DIN 46341 PARALLEL & BUTT CONNECTORS NON-INSULATED DIN 46211 TUBULAR CABLE LUGS RING TYPE (SR SERIES) OPEN BARREL DIN 46247 FEMALE DISCONNECTORS OPEN BARREL DIN 46248 MALE DISCONNECTORS VINYL-INSULATED DIN 46237 RING TERMINALS 10 3.OPEN BARREL TERMINALS 4.VINYL-INSULATED TERMINALS (V SERIES) 11 15 16 18 19 21 22 VINYL-INSULATED DIN 46237 SPADE TERMINALS 25 1.NON-INSULATED COPPER TUBULAR LUGS (TLD SERIES) NON-INSULATED DIN 46235 COPPER TUBULAR LUGS 7
2 INDEX K. S. TERMINALS INC. VINYL-INSULATED (EASY ENTRY) DIN 46237 RING TERMINALS VINYL-INSULATED (EASY ENTRY) DIN 46237 SPADE TERMINALS NYLON-INSULATED DIN 46237 RING TERMINALS PC-INSULATED DIN 46237 RING TERMINALS PC-INSULATED DIN 46237 SPADE TERMINALS NON-INSULATED DIN 46228 CORD END TERMINALS NYLON-INSULATED DIN 46228 CORD END TERMINALS NYLON-INSULATED DIN 46237 SPADE TERMINALS B.CORD END TERMINALS 1.NON-INSULATED TERMINALS (EN SERIES) 5.VINYL-INSULATED (EASY ENTRY) TERMINALS (VE SERIES) 6.NYLON-INSULATED TERMINALS (NY SERIES) 7.PC-INSULATED TERMINALS (NI SERIES) C.PLASTIC STRIP ON REEL TYPE (NYLON-INSULATED PS SERIES) NYLON-INSULATED DIN 46237 RING TERMINALS NYLON-INSULATED DIN 46237 SPADE TERMINALS 28 29 33 26 34 36 47 49 37 43
NON-INSULATED BUTTED SEAM TERMINAL DESCRIPTION 1 N TYPE VINYL INSULATED SINGLE CRIMP TERMINAL V TYPE PC INSULATED SINGLE CRIMP TERMINAL NI TYPE NON-INSULATED BRAZED SEAM TERMINAL NB TYPE VINYL EASY ENTRY INSULATED SINGLE CRIMP TERMINAL VE TYPE NYLON INSULATED SINGLE CRIMP TERMINAL NY TYPE BARREL TYPES K. S. TERMINALS INC. 3
DESCRIPTION 2 TERMINALS TYPE DR - TERMINAL TYPE , SEE DESCRIPTION 2 NY - BARREL TYPE , SEE DESCRIPTION 1 : DIN 46247 OPEN BARREL FEMALE DISCONNECTORS DOF : DIN 46248 OPEN BARREL MALE DISCONNECTORS DOM : DIN 46237 VINYL-INSULATED RING TERMINALS DRV : DIN 4637 VINYL-SPADE TERMINALS DSV : DIN 46237 VINYL-INSULATED (EASY ENTRY) RING TERMINALS DRVE : DIN 46237 VINYL-INSULATED (EASY ENTRY) SPADE TERMINALS DSVE : DIN 46237 NYLON-INSULATED RING TERMINALS DRNY : DIN 46237 NYLON-INSULATED SPADE TERMINALS DSNY : DIN 46237 PC-INSULATED RING TERMINALS DRNI : DIN 46237 PC-INSULATED SPADE TERMINALS DSNI : DIN 46228 NON-INSULATED CORD END TERMINALS EN : DIN 46228 NYLON-INSULATED CORD END TERMINALS E : DIN 46230 PIN TERMINALS PT : DIN 46234 RING TERMINALS DR : DIN 46234 SPADE TERMINALS DS : DIN 46341 PARALLEL DP : DIN 46341 BUTT DB : DIN 46211 TUBULAR CABLE LUG RING TYPE SR B - BRAZED SEAM EXAMPLE FOR YOUR ORDER ITEM NO. DRNYBS5-1 K. S. TERMINALS INC. 4 S - WIDTH , SEE THE WIDTH SIZE IN OUR CATALOGUE 5 - WIRE RANGE , SEE DESCRIPTION 3 1 - STUD SIZE , SEE DESCRIPTION 4
DESCRIPTION 3 #2 2.2 .087 #3 2.7 .106 #4 3.2 .126 #6 3.7 .146 #8 4.3 .169 #10 5.3 .209 1/4 6.4 .252 1/2 13.0 .512 9/16 15.0 .591 5/8 17.0 .669 3/4 21.0 .827 7/8 23.0 .906 11/16 19.0 .748 15/16 25.0 .984 1 28.0 1.102 5/16 8.4 .331 3/8 10.5 .413 7/16 11.5 .453 stud size mm inch stud size mm inch K. S. TERMINALS INC. 5
DESCRIPTION 4 WIRE RANGE 0.5 1 2.5 6 10 16 25 35 50 70 95 120 150 185 240 0.2-0.5 0.5-1.5 1.5-2.5 2.5-6 10 16 25 35 50 70 95 120 150 185 240 26-22 22-16 16-14 12-10 8 6 4 2 1/0 2/0 3/0 4/0 250/300 MCM 400 MCM A.W.G. mm2 K. S. TERMINALS INC. 6 300/350 MCM
TLD14-35 14.5 14.5 15.0 100 TLD16-50 19.0 16.0 17.0 50 28.0 S b d1 d3 d2 C1 C2 l a 1/0 A.W.G. 2 50 mm NOVOPRESS MODEL HPM400 14.5 10.0 52.0 4.0 WIRE RANGE A.W.G. 2 mm ITEM NO. CRIMPING TOOL Q'TY BOX 10.0 12.5 7.0 8.2 5.5 8.5 36.0 38.0 42.0 2.5 3.0 3.5 24.0 27.0 1.5 1.5 5.5 6.0 3.8 4.5 MAXIMUM ELECTRIC CURRENT: TERMINAL MATERIAL: COPPER TUBULAR 4 2 1/0 125 170 230 10 50 8 70 6 95 12 35 A.W.G. AMP. 6 A.W.G. 2 16 mm 12-10 A.W.G. 2 6 mm 8 A.W.G. 2 10 mm 4 A.W.G. 2 25 mm 2 A.W.G. 2 35 mm DIMENSION mm NOVOPRESS MODEL HPM400 IZUMI MODEL 5N18 OR K.S. MODEL LY-2045D WITH DIE INDEX NO:5.5 NOVOPRESS MODEL HPM400 NOVOPRESS MODEL HPM400 IZUMI MODEL 5N18 OR K.S. MODEL LY-2045D WITH DIE INDEX NO:5.5 DIN 46235 TLD5-6 a b C1C2 d1 d2 d3 I S TLD6-6 TLD5-10 TLD6-10 TLD8-6 TLD8-10 TLD8-16 TLD10-16 TLD6-16 TLD12-16 TLD8-25 TLD10-25 TLD6-25 TLD12-25 TLD6-35 TLD10-35 TLD12-35 TLD8-35 TLD8-50 TLD12-50 TLD14-50 TLD10-50 10.0 20.0 20.0 20.0 10.0 28.0 8.5 13.0 9.0 11.5 13.0 17.0 19.0 14.0 16.0 17.0 19.0 17.0 19.0 21.0 20.0 22.0 24.0 9.0 10.0 9.0 10.0 10.5 15.0 13.5 10.5 13.0 15.0 16.0 7.5 15.0 13.0 13.0 15.0 16.0 10.5 13.0 10.5 16.0 14.5 6.0 10.0 6.0 10.0 8.0 12.0 14.0 8.0 10.0 12.0 13.0 8.0 12.0 10.0 10.0 12.0 13.0 8.0 10.0 8.0 13.0 14.5 5.3 8.4 5.3 8.4 6.4 10.5 13.0 6.4 8.4 10.5 13.0 6.4 10.5 8.4 8.4 10.5 13.0 6.4 8.4 6.4 13.0 15.0 500 500 500 200 200 200 100 100 100 100 100 100 100 50 50 50 500 200 100 50 : DEVELOPING ON DEMAND 500 500 K. S. TERMINALS INC. NON-INSULATED TERMINALS 7
S b d1 d3 d2 C1 C2 l a 4/0 A.W.G. 2 120 mm TLD16-95 32.0 19.0 16.0 17.0 25 TLD20-120 22.0 20.0 21.0 25 32.0 TLD10-185 15.0 12.0 10.5 TLD20-185 22.0 20.0 21.0 10 10 40.0 WIRE RANGE A.W.G. 2 mm ITEM NO. CRIMPING TOOL Q'TY BOX TLD8-70 21.0 23.5 25.5 19.0 65.0 70.0 78.0 82.0 5.0 5.5 6.0 6.0 16.5 55.0 4.5 MAXIMUM ELECTRIC CURRENT: TERMINAL MATERIAL: COPPER TUBULAR 350 505 4/0 360 250 405 300 445 3/0 310 A.W.G. AMP. 300/350 MCM 2 185 mm 250/300 MCM 2 150 mm 3/0 A.W.G. 2 95 mm 2/0 A.W.G. 2 70 mm MODEL HPM400 NO OPRESS NO OPRESS NO OPRESS NO OPRESS NO OPRESS MODEL HPM400 MODEL HPM400 MODEL HPM400 MODEL HPM400 DIN 46235 DIMENSION mm a b C1C2 d1 d2 d3 I S TLD10-70 TLD12-70 TLD14-70 TLD16-70 TLD8-95 TLD10-95 TLD12-95 TLD14-95 TLD10-120 TLD12-120 TLD14-120 TLD16-120 TLD10-150 TLD12-150 TLD14-150 TLD16-150 TLD20-150 TLD12-185 TLD14-185 TLD16-185 28.0 35.0 35.0 35.0 40.0 24.0 30.0 28.0 38.0 34.0 40.0 37.0 13.0 16.0 14.5 12.0 15.0 14.5 15.0 16.0 17.5 19.0 15.0 18.5 16.0 16.0 18.5 19.0 16.0 15.0 19.0 22.0 19.0 10.0 13.0 14.5 12.0 12.0 14.5 12.0 13.0 19.0 16.0 12.0 20.0 13.0 13.0 20.0 16.0 13.0 12.0 16.0 20.0 16.0 11.5 15.5 17.0 13.5 19.0 8.4 13.0 15.0 8.4 10.5 15.0 10.5 13.0 15.0 17.0 10.5 15.0 13.0 13.0 15.0 17.0 13.0 10.5 17.0 21.0 17.0 50 50 50 25 25 25 25 25 25 25 25 25 25 10 10 50 25 50 25 25 10 2/0 265 : DEVELOPING ON DEMAND K. S. TERMINALS INC. NON-INSULATED TERMINALS 8
b d2 s C1 C2 a d1 d3 l 500 MCM 2 300 mm 600/750 MCM 2 400 mm 800/1000 MCM 2 500 mm 1000/1250 MCM 2 625 mm 1500/1750 MCM 2 800 mm 2000 MCM 2 1000 mm NOVOPRESS MODEL HPM400 NOVOPRESS MODEL HPM400 NOVOPRESS MODEL HPM400 TLD12-300 18.5 22.0 13.0 5 TLD16-500 23.0 27.0 17.0 5 WIRE RANGE A.W.G. 2 mm ITEM NO. CRIMPING TOOL Q'TY BOX TLD12-240 A.W.G. AMP. 400 MCM 2 240 mm DIMENSION mm DIN 46235 a b C1C2 d1 d2 d3 I S TLD14-240 TLD16-240 TLD20-240 TLD14-300 TLD16-300 TLD20-300 TLD14-400 TLD16-400 TLD20-400 TLD20-500 TLD20-625 TLD20-800 TLD20-1000 40.0 70.0 70.0 50.0 80.0 100.0 100.0 45.0 48.0 55.0 42.0 60.0 60.0 75.0 85.0 22.0 19.0 25.0 18.5 25.0 25.0 25.0 25.0 23.0 19.0 16.0 18.5 22.0 20.0 16.0 16.0 20.0 20.0 20.0 20.0 20.0 27.0 16.0 13.0 22.0 20.0 20.0 21.5 31.0 27.5 24.5 34.5 40.0 44.0 21.0 17.0 17.0 15.0 21.0 21.0 21.0 21.0 15.0 17.0 13.0 15.0 21.0 21.0 29.0 42.0 38.5 32.0 44.0 52.0 58.0 92.0 125.0 115.0 100.0 135.0 165.0 165.0 6.5 10.0 10.0 7.0 10.0 12.0 14.0 10 5 5 10 5 2 2 2 5 10 10 5 5 5 400 500 545 620 600 690 700 755 750 785 1000 1250 1500 1750 2000 935 1065 1175 1280 1385 800 815 900 870 MAXIMUM ELECTRIC CURRENT: TERMINAL MATERIAL: COPPER TUBULAR K. S. TERMINALS INC. NON-INSULATED TERMINALS 9
WIRE RANGE A.W.G. 2 mm ITEM NO. BRAZED SEAM BUTTED SEAM b a D l1 l2 d1 h T DIMENSION mm CRIMPING TOOL Q'TY BOX PTNB10-12 4.3 1000 500 400 200 100 50 50 8 A.W.G. 2 10 mm 6 A.W.G. 2 16 mm 4 A.W.G. 2 25 mm 1/0 A.W.G. 2 50 mm 2/0 A.W.G. 2 70 mm 2 A.W.G. 2 35 mm 3/0 A.W.G. 2 95 mm IZUMI MODEL 5N18 WITH DIE INDEX NO:8 OR K.S. MODEL KST2000D-1322 WITH DIE INDEX NO:8 K.S. MODEL LY-2045E WITH DIE INDEX NO:25 K.S. MODEL KH-120 WITH DIE INDEX NO:35 K.S. MODEL KH-120 WITH DIE INDEX NO:50 K.S. MODEL KH-120 WITH DIE INDEX NO:70 K.S. MODEL KH-120 WITH DIE INDEX NO:95 a l1 l2 d1 h b D Brazed Seam DIN 46230 Equivalent : NOT UL AND C-UL LISTED ALL LISTED IZUMI MODEL 9H-60 WITH DIE INDEX NO:14 OR K.S. MODEL LY-2045E WITH DIE INDEX NO:16 PTNB16-13 PTNB25-15 PTNB35-20 PTNB50-20 PTNB70-25 PTNB95-25 5.5 6.8 8.0 9.5 11.0 12.5 12.0 13.0 15.0 20.0 20.0 23.5 23.5 22.0 26.0 33.5 40.5 45.0 55.0 55.0 8.0 10.0 13.5 16.0 19.0 24.0 24.0 6.9 8.4 9.5 11.8 13.6 15.8 18.9 4.5 5.8 7.0 8.4 9.6 11.4 13.5 2.4 2.6 2.6 3.2 3.8 4.2 5.2 1.1 1.2 1.2 1.5 1.8 2.0 2.5 PTNB50-25 9.5 25.0 A.W.G. AMP. 2 170 1/0 230 8 70 6 95 4 125 2/0 265 3/0 310 TERMINAL MATERIAL: COPPER MAXIMUM ELECTRIC CURRENT: DIN TERMINALS K. S. TERMINALS INC. 10
WIRE RANGE A.W.G. 2 mm ITEM NO. STUD SIZE d2 d3 C I a d1 S CRIMPING TOOL Q'TY BOX #2 2.2 4.0 2.0 1.0 0.5 5.0 4.0 1.6 0.8 5.0 4.5 2.3 0.8 26-22 A.W.G. 0.2-0.5 2 mm 22-16 A.W.G. 0.5-1.5 2 mm 16-14 A.W.G. 1.5-2.5 2 mm DRNB2-0.5 K.S. MODEL KSTHT-5321 WITH DIE INDEX NO:(INSUL)16-22 IZUMI MODEL 5N18 WITH DIE INDEX NO:1.25 OR K.S. MODEL KST2000D-1322 LY-2045A WITH DIE INDEX NO:1.25 DIN 46234 Equivalent DIMENSION mm S a l d2 d3 d1 C Brazed Seam IZUMI MODEL 5N18 WITH DIE INDEX NO:2 OR K.S. MODEL KST2000D-1322 LY-2045A WITH DIE INDEX NO:2 DRNBS4-2.5 #8 4.3 11.6 DRNB3-2.5 DRNB3.5-2.5 #4 #6 3.2 3.7 11.0 DRNB2.5-0.5 DRNB3-0.5 DRNB3.5-0.5 DRNB4-0.5 DRNB5-0.5 DRNB2-1 DRNB2.5-1 DRNB3-1 DRNB3.5-1 DRNBS4-1 DRNB4-1 DRNBS5-1 DRNB5-1 DRNB6-1 DRNBL6-1 DRNB8-1 DRNB10-1 DRNBL10-1 #3 #4 #6 #8 #10 #2 #3 #4 #6 #8 #8 #10 #10 1/4 1/4 5/16 3/8 3/8 2.7 3.2 3.7 4.3 5.3 2.2 2.7 3.2 3.7 4.3 4.3 5.3 5.3 6.5 6.5 8.4 10.5 10.5 6.8 6.0 5.0 6.0 6.5 8.0 6.0 7.0 8.0 10.0 11.0 14.0 18.0 10.0 12.0 11.0 11.5 12.0 13.0 15.0 17.0 19.0 12.5 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 ALL LISTED #2 2.0 DRNBS2-0.5 1000 4.4 A.W.G. AMP. 20 12 18 17 26 5.5 24 7 22 9 16 18 14 30 TERMINAL MATERIAL: COPPER MAXIMUM ELECTRIC CURRENT: DIN TERMINALS K. S. TERMINALS INC. 11
WIRE RANGE A.W.G. 2 mm ITEM NO. STUD SIZE d2 d3 C I a d1 S DIMENSION mm CRIMPING TOOL Q'TY BOX #8 4.3 5.0 4.5 2.3 0.8 6.0 6.0 3.6 1.0 8.0 8.0 4.5 1.1 DRNB4-2.5 IZUMI MODEL 5N18 WITH DIE INDEX NO:8 OR K.S. MODEL KST2000D-1322 LY-2045A WITH DIE INDEX NO:8(10) IZUMI MODEL 5N18 WITH DIE INDEX NO:5.5 OR K.S. MODEL KST2000D-1322 LY-2045A WITH DIE INDEX NO:5.5(6.0) IZUMI MODEL 5N18 WITH DIE INDEX NO:2 OR K.S. MODEL KST2000D-1322 LY-2045A WITH DIE INDEX NO:2 16-14 A.W.G. 1.5-2.5 2 mm 12-10 A.W.G. 2.5-6 2 mm 8 A.W.G. 2 10 mm S a l d2 d3 d1 C Brazed Seam DRNBS5-2.5 DRNB5-2.5 DRNB6-2.5 DRNB8-2.5 DRNB10-2.5 DRNBL10-2.5 DRNB12-2.5 DRNB3.5-6 DRNB4-6 DRNB5-6 DRNB6-6 DRNBL6-6 DRNB8-6 DRNB10-6 DRNB12-6 DRNB5-10 DRNB6-10 DRNB8-10 DRNB10-10 DRNB12-10 #10 #10 1/4 5/16 3/8 3/8 1/2 #6 #8 #10 1/4 1/4 5/16 3/8 1/2 #10 1/4 5/16 3/8 1/2 5.3 6.5 8.4 10.5 13.0 3.7 4.3 5.3 6.5 6.5 8.4 10.5 13.0 5.3 6.5 8.4 10.5 13.0 8.0 10.0 11.0 14.0 15.0 18.0 8.0 10.0 11.0 18.0 14.0 18.0 10.0 11.0 14.0 18.0 22.0 12.0 14.0 16.0 17.0 18.5 20.0 13.5 15.0 16.0 21.0 19.0 21.0 16.0 17.0 20.0 21.0 23.0 13.5 14.0 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 500 500 500 500 500 500 500 10.5 5.3 DRNB3-6 #4 3.2 14.0 1000 6.0 DRNBL3-6 #4 3.2 1000 7.2 DRNB4-10 #8 4.3 500 ALL LISTED A.W.G. AMP. 10 50 8 70 16 18 14 30 12 35 TERMINAL MATERIAL: COPPER MAXIMUM ELECTRIC CURRENT: DIN 46234 Equivalent DIN TERMINALS K. S. TERMINALS INC. 12
WIRE RANGE A.W.G. 2 mm ITEM NO. STUD SIZE d2 d3 C I a d1 S CRIMPING TOOL Q'TY BOX 10.0 11.0 10.5 12.0 5.8 7.5 1.2 1.5 12.0 15.0 9.0 1.6 16.0 17.0 11.0 1.8 6 A.W.G. 2 16 mm 4 A.W.G. 2 25 mm 2 A.W.G. 2 35 mm 1/0 A.W.G. 2 50 mm DRNB5-16 IZUMI MODEL 9H-60 WITH DIE INDEX NO:14 OR KLAUKE MODEL PK25 WITH DIE INDEX NO.:HQ25/16 OR K.S. MODEL LY-2045E OR KSTP-325T WITH DIE INDEX NO:16 IZUMI MODEL 9H-60 WITH DIE INDEX NO:22 OR KLAUKE MODEL PK25 WITH DIE INDEX NO.:HQ25/25 OR K.S. MODEL KSTP-325T WITH DIE INDEX NO:25 IZUMI MODEL 9H-60 WITH DIE INDEX NO:38 OR KLAUKE MODEL PK25 WITH DIE INDEX NO:HQ25/35 OR K.S. MODEL KSTP-325T WITH DIE INDEX NO:35 IZUMI MODEL 9H-60 WITH DIE INDEX NO:60 OR KLAUKE MODEL PK25 WITH DIE INDEX NO:HQ25/50 OR K.S. MODEL KH-150 OR KSTP-325T WITH DIE INDEX NO:50 DIMENSION mm S d1 d2 d3 C a l Brazed Seam DRNB6-16 DRNB8-16 DRNB10-16 DRNB12-16 DRNB5-25 DRNB6-25 DRNB8-25 DRNB10-25 DRNB12-25 DRNB16-25 DRNB6-35 DRNB8-35 DRNB10-35 DRNB12-35 DRNB16-35 DRNB6-50 DRNB8-50 DRNB10-50 DRNB12-50 DRNB16-50 #10 1/2 1/4 5/16 3/8 1/2 #10 1/4 5/16 3/8 1/2 5/8 1/4 5/16 3/8 1/2 5/8 1/4 5/16 3/8 5/8 5.3 13.0 6.5 8.4 10.5 13.0 5.3 6.5 8.4 10.5 13.0 17.0 6.5 8.4 10.5 13.0 17.0 6.5 8.4 10.5 17.0 11.0 22.0 11.0 14.0 18.0 22.0 12.0 12.0 16.0 18.0 22.0 28.0 15.0 16.0 18.0 22.0 28.0 18.0 18.0 18.0 28.0 20.0 36.0 20.0 22.0 24.0 26.0 25.0 25.0 25.0 26.0 31.0 35.0 26.0 26.0 27.0 31.0 36.0 34.0 34.0 34.0 40.0 500 100 500 500 500 400 250 250 250 200 200 200 250 200 200 200 100 100 100 100 100 ALL LISTED DRNB4-16 #8 4.3 500 DRNB11-35 7/16 11.5 22.0 31.0 200 A.W.G. AMP. 2 170 1/0 230 6 95 4 125 TERMINAL MATERIAL: COPPER MAXIMUM ELECTRIC CURRENT: DIN 46234 Equivalent DIN TERMINALS K. S. TERMINALS INC. 13
WIRE RANGE A.W.G. 2 mm ITEM NO. STUD SIZE d2 d3 C I a d1 S CRIMPING TOOL Q'TY BOX 1/4 5/16 3/8 1/2 5/8 5/16 3/8 1/2 5/8 5/16 3/8 1/2 5/8 3/8 1/2 5/8 3/8 1/2 5/8 3/8 1/2 5/8 6.5 8.4 10.5 13.0 17.0 8.4 10.5 13.0 17.0 8.4 10.5 13.0 17.0 10.5 13.0 17.0 10.5 13.0 17.0 10.5 13.0 17.0 22.0 28.0 24.0 28.0 24.0 28.0 30.0 36.0 38.0 18.0 20.0 21.0 23.0 13.0 15.0 2.0 2.5 22.0 24.0 28.0 24.0 28.0 33.0 16.5 19.0 21.0 3.0 3.2 3.5 32.0 36.0 23.5 4.0 100 100 100 100 100 50 50 50 50 50 50 50 50 25 25 25 25 25 25 25 25 25 2/0 A.W.G. 2 70 mm 3/0 A.W.G. 2 95 mm 4/0 A.W.G. 2 120 mm 250/300 MCM 2 150 mm 300-350 MCM 2 185 mm 400 MCM 2 240 mm DRNB6-70 DRNB8-70 DRNB10-70 DRNB12-70 DRNB16-70 DRNB8-95 DRNB10-95 DRNB12-95 DRNB16-95 DRNB8-120 DRNB10-120 DRNB12-120 DRNB16-120 DRNB10-150 DRNB12-150 DRNB16-150 DRNB10-185 DRNB12-185 DRNB16-185 DRNB10-240 DRNB12-240 DRNB16-240 IZUMI MODEL 9H-150 WITH DIE INDEX NO:70 OR KLAUKE MODEL PK 25/2 WITH DIE INDEX NO:HQ25/70 OR K.S. MODEL KH-150 OR KSTP-325T WITH DIE INDEX NO:70 IZUMI MODEL 9H-150 WITH DIE INDEX NO:80 OR KLAUKE MODEL PK 25/2 WITH DIE INDEX NO:95 OR K.S. MODEL KH-150 OR KSTP-325T WITH DIE INDEX NO:95 IZUMI MODEL 9H-150 WITH DIE INDEX NO:100 OR KLAUKE MODEL PK 25/2 WITH DIE INDEX NO:HQ25/120 OR K.S. MODEL KH-150 OR KSTP-325T WITH DIE INDEX NO:120 IZUMI MODEL 9H-150 WITH DIE INDEX NO:150 OR KLAUKE MODEL PK 25/2 WITH DIE INDEX NO:HQ25/150 OR K.S. MODEL KH-150 WITH DIE INDEX NO:150 KLAUKE MODEL PK 25/2 WITH DIE INDEX NO:HQ25/185 OR K.S. MODEL KSTP-325T WITH DIE INDEX NO:185 KLAUKE MODEL PK 25/2 WITH DIE INDEX NO:HQ25/240 OR K.S. MODEL KSTP-325T WITH DIE INDEX NO:240 38.0 42.0 42.0 44.0 44.0 48.0 50.0 50.0 56.0 DIMENSION mm S d1 d2 d3 C a l Brazed Seam ALL LISTED A.W.G. AMP. 250 405 300 445 2/0 265 3/0 310 4/0 360 350 505 400 545 500 620 TERMINAL MATERIAL: COPPER MAXIMUM ELECTRIC CURRENT: DRNB8-150 5/16 8.4 25 DIN 46234 Equivalent DIN TERMINALS K. S. TERMINALS INC. 14
WIRE RANGE A.W.G. 2 mm ITEM NO. STUD SIZE d2 d3 C I a d1 S CRIMPING TOOL Q'TY BOX #2 5.0 4.0 5.0 2.0 4.0 1.0 1.6 0.5 0.8 5.0 4.5 2.3 0.8 6.0 6.0 3.6 1.0 26-22 A.W.G. 0.2-0.5 2 mm 22-16 A.W.G. 0.5-1.5 2 mm 16-14 A.W.G. 1.5-2.5 2 mm 12-10 A.W.G. 2.5-6 2 mm DSNB2-0.5 K.S. MODEL KSTHT-5321 WITH DIE INDEX NO:(INSUL)16-22 IZUMI MODEL 5N18 WITH DIE INDEX NO:1.25 OR K.S. MODEL KST2000D-1322 LY-2045A WITH DIE INDEX NO:1.25 IZUMI MODEL 5N18 WITH DIE INDEX NO:2 OR K.S. MODEL KST2000D-1322 LY-2045A WITH DIE INDEX NO:2 IZUMI MODEL 5N18 WITH DIE INDEX NO:5.5 OR K.S. MODEL KST2000D-1322 LY-2045A WITH DIE INDEX NO:5.5 A.W.G. AMP. 20 12 18 17 26 5.5 24 7 22 9 16 18 14 30 12 35 10 50 TERMINAL MATERIAL: COPPER MAXIMUM ELECTRIC CURRENT: DIMENSION mm d2 S d3 a l d1 C Brazed Seam DSNB3-0.5 DSNB3.5-0.5 DSNB4-0.5 DSNB5-0.5 DSNB3-1 DSNB3.5-1 DSNB4-1 DSNBL4-1 DSNB5-1 DSNB6-1 DSNB3-2.5 DSNB3.5-2.5 DSNB4-2.5 DSNBL4-2.5 DSNB5-2.5 DSNB6-2.5 DSNB4-6 DSNB5-6 DSNB6-6 DSNB8-6 DSNB10-6 #4 #6 #8 #10 #4 #6 #8 #8 #10 1/4 #4 #6 #8 #8 #10 1/4 #8 #10 1/4 5/16 3/8 2.2 3.2 3.7 4.3 5.3 3.2 3.7 4.3 5.3 6.5 3.2 3.7 4.3 5.3 6.5 4.3 5.3 6.5 8.4 10.5 6.0 6.5 8.0 6.0 6.8 8.0 10.0 11.0 5.5 6.0 6.8 10.0 11.0 8.0 10.0 11.0 14.0 18.0 8.0 8.0 11.0 11.0 12.0 13.0 15.0 13.0 11.0 14.0 16.0 14.0 15.0 16.0 19.0 21.0 12.0 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 500 ALL LISTED 4.3 4.3 DIN 46234 Equivalent DIN TERMINALS K. S. TERMINALS INC. 15
WIRE RANGE A.W.G. 2 mm ITEM NO. PARALLEL BUTT I I a d S DIMENSION inch mm CRIMPING TOOL Q'TY BOX .315 8.0 .591 15.0 DPNT1 16-14 A.W.G. 1.5-2.5 2 mm 22-16 A.W.G. 0.5-1.5 2 mm 12-10 A.W.G. 2.5-6 2 mm 8 A.W.G. 2 10 mm 6 A.W.G. 2 16 mm 4 A.W.G. 2 25 mm 2 A.W.G. 2 35 mm 1/0 A.W.G. 2 50 mm IZUMI MODEL 5N18 WITH DIE INDEX NO:1.25 OR K.S. MODEL KST2000D-1322 WITH DIE INDEX NO:22-18 IZUMI MODEL 5N18 WITH DIE INDEX NO:2 OR K.S. MODEL KST2000D-1322 WITH DIE INDEX NO:16-14 IZUMI MODEL 5N18 WITH DIE INDEX NO:5.5 OR K.S. MODEL KST2000D-1322 WITH DIE INDEX NO:12-10 IZUMI MODEL 5N18 WITH DIE INDEX NO:8 OR K.S. MODEL KST2000D-1322 WITH DIE INDEX NO:8 KLAUKE MODEL PK 25 WITH DIE INDEX NO:HQ25/16 KLAUKE MODEL PK 25 WITH DIE INDEX NO:HQ25/25 KLAUKE MODEL PK 25 WITH DIE INDEX NO:HQ25/35 KLAUKE MODEL PK 25 WITH DIE INDEX NO:HQ25/50 s d l s d a a l BUTT PARALLEL DIN 46341 Equivalent DPNT2.5 DPNT6 DPNT10 DPNT16 DPNT25 DPNT35 DPNT50 .315 8.0 .354 9.0 .394 10.0 .433 11.0 .551 14.0 .630 16.0 .748 19.0 DBNT1 DBNT2.5 DBNT6 DBNT10 DBNT16 DBNT25 DBNT35 DBNT50 .591 15.0 .591 15.0 .827 21.0 1.024 26.0 1.142 29.0 1.260 32.0 1.496 38.0 .197 5.0 .197 5.0 .236 6.0 .315 8.0 .394 10.0 .433 11.0 .472 12.0 .630 16.0 .063 1.6 .091 2.3 .142 3.6 .177 4.5 .228 5.8 .295 7.5 .354 9.0 .433 11.0 .031 0.8 .035 0.9 .039 1.0 .043 1.1 .047 1.2 .059 1.5 .063 1.6 .071 1.8 1000 1000 1000 1000/500 1000/500 1000/250 1000/200 500/50 ALL LISTED DPNT2.5-5 .197 5.0 DPNT6-7 .276 7.0 DPNT16-10 .394 10.0 A.W.G. AMP. 16 18 14 30 22 9 20 12 18 17 12 35 10 50 6 95 4 125 8 70 2 170 1/0 230 MATERIAL: COPPER TUBULAR MAXIMUM ELECTRIC CURRENT: DPNT6-5 .197 5.0 DIN TERMINALS K. S. TERMINALS INC. 16
WIRE RANGE A.W.G. 2 mm ITEM NO. PARALLEL BUTT I I a d S DIMENSION inch mm CRIMPING TOOL Q'TY BOX .748 19.0 DPNT70 3/0 A.W.G. 2 95 mm 2/0 A.W.G. 2 70 mm 4/0 A.W.G. 2 120 mm 250/300 MCM 2 150 mm KLAUKE MODEL PK 25/2 WITH DIE INDEX NO:HQ25/70 KLAUKE MODEL PK 25/2 WITH DIE INDEX NO:HQ25/95 KLAUKE MODEL PK 25/2 WITH DIE INDEX NO:HQ25/120 KLAUKE MODEL PK 25/2 WITH DIE INDEX NO:HQ25/150 DIN 46341 Equivalent s d l s d a a l BUTT PARALLEL DPNT95 DPNT120 DPNT150 .787 20.0 .866 22.0 1.024 26.0 DBNT70 DBNT95 DBNT120 DBNT150 1.654 42.0 1.890 48.0 2.047 52.0 2.205 56.0 .669 17.0 .709 18.0 .787 20.0 .945 24.0 .512 13.0 .591 15.0 .650 16.5 .748 19.0 .079 2.0 .098 2.5 .118 3.0 .126 3.2 500/50 500/25 500/25 500/10 ALL LISTED A.W.G. AMP. 250 405 300 445 2/0 265 3/0 310 4/0 360 MATERIAL: COPPER TUBULAR MAXIMUM ELECTRIC CURRENT: DIN TERMINALS K. S. TERMINALS INC. 17
WIRE RANGE A.W.G. 2 mm ITEM NO. d3 l a S DIMENSION mm CRIMPING TOOL Q'TY BOX 12-10 A.W.G. 2.5-6 2 mm 10-6 A.W.G. 6-16 2 mm 8-4 A.W.G. 10-25 2 mm 6-2 A.W.G. 16-35 2 mm 4-0 A.W.G. 25-50 2 mm 2-2/0 A.W.G. 35-70 2 mm 0-3/0 A.W.G. 50-95 2 mm 2/0-4/0 A.W.G. 70-120 2 mm SR4-2.5-B Size Bolt - 2 mm (d2) #8 4 3.4 DIN 46211 Equivalent S d2 d3 a l SR5-2.5-B SR6-2.5-B SR6-6-B SR8-6-B SR10-6-B SR6-10-B SR8-10-B SR10-10-B SR6-16-B SR8-16-B SR10-16-B SR12-16-B SR8-25-B SR10-25-B SR12-25-B SR8-35-B SR10-35-B SR12-35-B SR10-50-B SR12-50-B SR10-70-B SR12-70-B 5 3.4 6 3.4 6 4.3 8 4.3 10 4.3 6 5.4 8 5.4 10 5.4 6 6.8 8 6.8 10 6.8 12 6.8 8 8.2 10 8.2 12 8.2 8 9.5 10 9.5 12 9.5 10 11.2 12 11.2 10 13.5 12 13.5 #10 1/4 1/4 5/16 3/8 1/4 5/16 3/8 1/4 5/16 3/8 1/2 5/16 3/8 1/2 5/16 3/8 1/2 3/8 1/2 32/8 1/2 8.0 10.0 11.0 11.0 15.0 19.0 11.0 15.0 19.0 13.0 15.0 19.0 22.0 15.0 19.0 22.0 17.0 19.0 22.0 21.0 22.0 21.0 22.0 16.0 18.0 19.0 21.0 24.0 26.0 24.0 27.0 29.0 27.0 30.0 32.0 35.0 33.0 35.0 38.0 36.0 38.0 41.0 44.0 47.0 44.0 47.0 8.2 10.2 11.6 13.8 16.4 19.5 24.5 24.5 1.0 1.2 1.5 1.8 2.0 2.5 3.0 3.5 1000 1000 1000 500 500 500 500 250 250 250 250 200 200 200 200 100 100 100 100 50 50 50 50 A.W.G. AMP. 6 95 4 125 2 170 12 35 10 50 8 70 4/0 360 1/0 230 2/0 265 3/0 310 MATERIAL: BRASS MAXIMUM ELECTRIC CURRENT: DIN TERMINALS K. S. TERMINALS INC. 18
WIRE RANGE A.W.G. 2 mm ITEM NO. NEAM TAB W b1 b2 F L h1 h2 T FIG DIMENSION mm CRIMPING TOOL Q'TY BOX DOF6.3-1LR 6.6 .032 .250 (0.8 6.35) 1000 1000 1000 1000 500 500 500 500 22-16 A.W.G. 0.5-1.5 2 mm 16-14 A.W.G. 1.5-2.5 2 mm 12-10 A.W.G. 2.5-6 2 mm F L b1 b2 h1 h2 W F L b2 b1 h2 h1 W FIG-1 FIG-2 A.W.G. AMP. 16 10 14 15 12 20 10 24 22 3 20 4 18 7 TERMINAL MATERIAL: BRASS LR: LOOSE PIECE, STANDARD CHEMICAL TREATMENT(BRASS FINISH) LT: LOOSE PIECE, TIN PLATED MAXIMUM ELECTRIC CURRENT: K.S. MODEL KST2000D-1306 WITH DIE INDEX NO:22-18 K.S. MODEL KST2000D-1306 WITH DIE INDEX NO:16-14 K.S. MODEL KST2000D-1306 WITH DIE INDEX NO:12-10 DIN 46247 Equivalent DOFS6.3-1LR DOF6.3-2.5LR DOFS6.3-2.5LR DOF6.3-4LR DOF6.3-6LR DOFS6.3-6LR DOF9.5-6LR .032 .250 (0.8 6.35) .032 .250 (0.8 6.35) .032 .250 (0.8 6.35) .032 .250 (0.8 6.35) .032 .250 (0.8 6.35) .032 .250 (0.8 6.35) .047 .375 (1.2 9.4) 6.8 6.6 6.8 6.6 6.6 6.6 10.0 7.5 7.5 7.5 7.5 7.5 7.5 7.5 12.4 19.2 19.2 19.2 19.2 19.2 19.2 19.2 24.4 2.0 2.0 2.2 2.2 3.0 3.0 3.0 3.0 2.0 2.0 3.0 3.0 4.0 4.0 4.0 4.0 2.5 2.5 3.6 3.6 4.2 5.8 5.8 4.0 4.0 4.0 5.0 5.0 5.5 5.7 5.7 5.5 0.4 0.4 0.4 0.4 0.4 0.4 0.4 0.45 1 2 1 2 1 1 2 1 DIN TERMINALS K. S. TERMINALS INC. 19
WIRE RANGE A.W.G. 2 mm ITEM NO. NEAM TAB W b1 b2 F L h1 h2 T FIG DIMENSION mm CRIMPING TOOL Q'TY BOX 1000 1000 1000 22-16 A.W.G. 0.5-1.5 2 mm 16-14 A.W.G. 1.5-2.5 2 mm 12-10 A.W.G. 2.5-6 2 mm F L b1 b2 h1 h2 W F L b2 b1 h2 h1 W FIG-1 FIG-2 A.W.G. AMP. 16 10 14 15 12 20 10 24 22 3 20 4 18 7 TERMINAL MATERIAL: BRASS LR: LOOSE PIECE, STANDARD CHEMICAL TREATMENT(BRASS FINISH) LT: LOOSE PIECE, TIN PLATED MAXIMUM ELECTRIC CURRENT: .032 .187 (0.8 4.75) .032 .250 (0.8 6.35) .032 .250 (0.8 6.35) 5.1 6.8 6.8 6.5 7.5 7.5 15.5 19.3 19.3 3.2 3.8 5.0 4.7 5.2 6.6 3.3 3.9 5.0 4.3 4.9 6.1 0.35 0.4 0.4 2 K.S.MODEL KST8000-LDO WITH DIE INDEX NO：22-16 1000 1000 1000 1000 1000 1000 1000 1000 1000 500 500 500 500 LDOF6.3-1LR LDOF6.3-1LT .032 .250 (0.8 6.35) 1 2 1 LDOFS6.3-1LR 6.8 7.5 19.3 3.0 4.4 2.7 4.3 0.4 LDOFS6.3-1LT 2 LDOFS4.8(8)-1LR 2 LDOFS4.8(8)-1LT .032 .110 (0.8 2.8) 3.3 6.3 14.0 2.8 3.9 2.6 4.2 2 LDOFS2.8(8)-1LR LDOFS2.8(8)-1LT 0.25 2 LDOF6.3-2.5LR LDOF6.3-2.5LT LDOFS6.3-2.5LR LDOFS6.3-2.5LT 1 2 1 2 K.S.MODEL KST8000-LDO WITH DIE INDEX NO：16-14 LDOF6.3-6LR-00 LDOF6.3-6LT-00 LDOFS6.3-6LR LDOFS6.3-6LT 1 2 1 2 K.S.MODEL KST8000-LDO WITH DIE INDEX NO：12-10 DIN TERMINALS K. S. TERMINALS INC. 20
WIRE RANGE A.W.G. 2 mm ITEM NO. NEAM TAB W b1 b2 F L h1 h2 T FIG DIMENSION mm CRIMPING TOOL Q'TY BOX DOM6.3-1LR 6.3 .032 .250 (0.8 6.35) 1000 1000 1000 500 22-16 A.W.G. 0.5-1.5 2 mm 16-14 A.W.G. 1.5-2.5 2 mm 12-10 A.W.G. 2.5-6 2 mm 1 1 2 1 K.S. MODEL KST2000D-1306 WITH DIE INDEX NO:22-18 K.S. MODEL KST2000D-1306 WITH DIE INDEX NO:16-14 K.S. MODEL KST2000D-1306 WITH DIE INDEX NO:12-10 DIN 46248 Equivalent FIG-1 FIG-2 DOM6.3-2.5LR DOMS6.3-2.5LR DOM6.3-6LR .032 .250 (0.8 6.35) .032 .250 (0.8 6.35) .032 .250 (0.8 6.35) 6.3 6.3 6.3 8.0 8.0 16.0 8.0 20.0 20.0 28.0 20.0 2.6 3.0 3.3 5.3 4.3 4.8 5.1 6.3 2.7 3.2 3.4 4.7 4.0 4.5 5.1 5.9 0.4 0.4 0.4 0.4 DOMS6.3-1LR 6.3 .032 .250 (0.8 6.35) 1000 2 16.0 28.0 3.0 5.2 3.0 4.5 0.4 500 2 DOMS6.3-6LR .032 .250 (0.8 6.35) 6.3 16.0 28.0 2.8 3.4 5.6 6.2 0.4 A.W.G. AMP. 16 10 14 15 12 20 10 24 22 3 20 4 18 7 TERMINAL MATERIAL: BRASS LR: LOOSE PIECE, STANDARD CHEMICAL TREATMENT(BRASS FINISH) LT: LOOSE PIECE, TIN PLATED MAXIMUM ELECTRIC CURRENT: DIN TERMINALS K. S. TERMINALS INC. 21
WIRE RANGE A.W.G. 2 mm ITEM NO. BUTTED SEAM BRAZED SEAM STUD SIZE DIMENSION mm CRIMPING TOOL Q'TY BOX DRVB2-1 #2 2.2 1.6 2.3 4.0 4.5 10.0 10.0 0.8 0.8 22-16 A.W.G. 0.5-1.5 2 mm 16-14 A.W.G. 1.5-2.5 2 mm IZUMI MODEL 34 WITH DIE INDEX COLOR:RED OR K.S. MODEL KST2000A HRI-126J KSTLY-2004 KSTLY-2005 WITH DIE INDEX COLOR:RED IZUMI MODEL 34 WITH DIE INDEX COLOR:BLUE OR K.S. MODEL KST2000A HRI-126J KSTLY-2004 KSTLY-2005 WITH DIE INDEX COLOR:BLUE d2 d3 l d1 d4 a S DIN 46237 Equivalent a l d2 d3 S d1 d4 DRVB2.5-1 DRVB3-1 DRVB3.5-1 DRVBS4-1 DRVB4-1 DRVBS5-1 DRVB5-1 DRVB6-1 DRVBL6-1 DRVB8-1 DRVB10-1 DRVBL10-1 DRVB3-2.5 DRVB3.5-2.5 DRVBS4-2.5 DRVB4-2.5 DRVBS5-2.5 DRVB5-2.5 DRVB6-2.5 DRVB8-2.5 DRVB10-2.5 DRV2-1 DRV2.5-1 DRV3-1 DRV3.5-1 DRVS4-1 DRV4-1 DRVS5-1 DRV5-1 DRV6-1 DRVL6-1 DRV8-1 DRV10-1 DRVL10-1 DRV3-2.5 DRV3.5-2.5 DRVS4-2.5 DRV4-2.5 DRVS5-2.5 DRV5-2.5 DRV6-2.5 DRV8-2.5 DRV10-2.5 #3 #4 #6 #8 #8 #10 #10 1/4 1/4 5/16 3/8 3/8 #4 #6 #8 #8 #10 #10 1/4 5/16 3/8 2.7 3.2 3.7 4.3 5.3 6.5 8.4 10.5 3.2 3.7 4.3 5.3 6.5 8.4 10.5 6.0 7.0 8.0 10.0 11.0 14.0 18.0 6.0 6.8 8.0 11.0 14.0 15.0 10.0 16.0 16.5 17.0 18.0 20.0 22.0 24.0 16.0 16.6 17.0 21.0 22.0 19.0 17.5 18.5 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 4.3 5.3 6.5 10.5 4.3 5.3 DRVBL10-2.5 DRVB12-2.5 DRVL10-2.5 DRV12-2.5 3/8 1/2 10.5 13.0 18.0 23.5 1000 1000 25.0 ALL LISTED K.S. MODEL KST2000A HRI-126J KSTLY-2004 KSTLY-2005 WITH DIE INDEX COLOR:BLUE 2.3 4.5 10.0 0.8 A.W.G. AMP. 16 18 14 30 22 9 20 12 18 17 22-16 A.W.G.: RED 16-14 A.W.G.: BLUE INSULATION MATERIAL: VINYL INSULATION COLOR: MAXIMUM ELECTRICAL RATING: 105 C 600 VOLTS MAX. MAXIMUM ELECTRIC CURRENT: TERMINAL MATERIAL: COPPER DIN TERMINALS K. S. TERMINALS INC. 22
WIRE RANGE A.W.G. 2 mm ITEM NO. BUTTED SEAM BRAZED SEAM STUD SIZE DIMENSION mm CRIMPING TOOL Q'TY BOX d2 d3 l d1 d4 a S DIN 46237 Equivalent a l d2 d3 S d1 d4 ALL LISTED 3.6 6.3 13.0 1.0 12-10 A.W.G. 2 2.5-6 mm IZUMI MODEL 5 WITH DIE INDEX COLOR:YELLOW OR K.S. MODEL KST2000A HRI-126J KSTLY-2004 KSTLY-2005 WITH DIE INDEX COLOR:YELLOW DRVB4-6 DRVB5-6 DRVB6-6 DRVB8-6 DRVB10-6 DRVB12-6 DRV4-6 DRV5-6 DRV6-6 DRV8-6 DRV10-6 DRV12-6 #8 #10 1/4 5/16 3/8 1/2 4.3 5.3 6.5 8.4 10.5 13.0 8.0 10.0 11.0 14.0 18.0 21.0 22.0 22.5 26.0 28.0 500 500 500 500 500 500 4.5 8.0 16.5 1.1 8 A.W.G. 2 10 mm DRVB4-10 DRVB5-10 DRVB6-10 DRVB8-10 DRVB10-10 DRVB12-10 #8 #10 1/4 5/16 3/8 1/2 4.3 5.3 6.5 8.4 10.5 13.0 10.0 11.0 14.0 18.0 24.5 25.5 28.5 29.5 500 500 500 500 250 250 22.0 31.5 5.8 10.5 21.5 1.2 6 A.W.G. 2 16 mm DRVB5-16 DRVB6-16 DRVB8-16 DRVB10-16 DRVB12-16 #10 5/16 3/8 5.3 6.5 8.4 10.5 13.0 11.0 14.0 18.0 22.0 31.5 33.5 35.5 37.5 250 100 100 100 100 1/4 1/2 7.5 13.0 24.0 1.5 4 A.W.G. 2 25 mm DRVB5-25 DRVB6-25 DRVB8-25 DRVB10-25 DRVB12-25 #10 5/16 3/8 5.3 6.5 8.4 10.5 13.0 12.0 16.0 18.0 22.0 38.0 39.0 44.0 100 100 100 100 100 1/4 1/2 DRVB16-25 17.0 28.0 48.0 100 5/8 DRVB3-6 DRV3-6 #4 3.2 6.0 21.0 500 : NOT UL AND C-UL LISTED A.W.G. AMP. 6 95 4 125 12 35 10 50 8 70 12-10 A.W.G.: YELLOW 8 A.W.G.: RED 6 A.W.G.: BLUE 4 A.W.G.: YELLOW INSULATION MATERIAL: VINYL INSULATION COLOR: MAXIMUM ELECTRICAL RATING: 105 C 600 VOLTS MAX. MAXIMUM ELECTRIC CURRENT: TERMINAL MATERIAL: COPPER DIN TERMINALS K. S. TERMINALS INC. 23
WIRE RANGE A.W.G. 2 mm ITEM NO. BUTTED SEAM BRAZED SEAM STUD SIZE DIMENSION mm CRIMPING TOOL Q'TY BOX d2 d3 l d1 d4 a S DIN 46237 Equivalent a l d2 d3 S d1 d4 ALL LISTED 9.0 14.5 27.0 1.6 2 A.W.G. 2 35 mm DRVB6-35 DRVB8-35 DRVB10-35 DRVB11-35 DRVB12-35 DRVB16-35 5/16 3/8 7/16 6.5 8.4 10.5 11.5 13.0 17.0 15.0 16.0 18.0 22.0 28.0 41.0 42.0 46.0 51.0 500 500 500 500 500 500 1/4 1/2 5/8 A.W.G. AMP. 2 170 2 A.W.G.: RED INSULATION MATERIAL: VINYL INSULATION COLOR: MAXIMUM ELECTRICAL RATING: 105 C 600 VOLTS MAX. MAXIMUM ELECTRIC CURRENT: TERMINAL MATERIAL: COPPER DIN TERMINALS K. S. TERMINALS INC. 24
WIRE RANGE A.W.G. 2 mm ITEM NO. BUTTED SEAM BRAZED SEAM STUD SIZE d2 d3 l d1 d4 a S DIMENSION mm CRIMPING TOOL Q'TY BOX DSVB3-1 #4 1.6 3.6 2.3 4.0 6.3 4.5 10.0 13.0 10.0 0.8 1.0 0.8 22-16 A.W.G. 0.5-1.5 2 mm 16-14 A.W.G. 1.5-2.5 2 mm 12-10 A.W.G. 2 2.5-6 mm IZUMI MODEL 5 WITH DIE INDEX COLOR:YELLOW OR K.S. MODEL KST2000A HRI-126J KSTLY-2004 KSTLY-2005 WITH DIE INDEX COLOR:YELLOW IZUMI MODEL 34 WITH DIE INDEX COLOR:BLUE OR K.S. MODEL KST2000A HRI-126J KSTLY-2004 KSTLY-2005 WITH DIE INDEX COLOR:BLUE IZUMI MODEL 34 WITH DIE INDEX COLOR:RED OR K.S. MODEL KST2000A HRI-126J KSTLY-2004 KSTLY-2005 WITH DIE INDEX COLOR:RED DIN 46237 Equivalent a l S d2 d3 d1 d4 DSVB3.5-1 DSVB4-1 DSVBL4-1 DSVB5-1 DSVB6-1 DSVB3-2.5 DSVB3.5-2.5 DSVB4-2.5 DSVBL4-2.5 DSVB5-2.5 DSVB6-2.5 DSVB4-6 DSVB5-6 DSVB6-6 DSVB8-6 DSVB10-6 DSV3-1 DSV3.5-1 DSV4-1 DSVL4-1 DSV5-1 DSV6-1 DSV3-2.5 DSV3.5-2.5 DSV4-2.5 DSVL4-2.5 DSV5-2.5 DSV6-2.5 DSV4-6 DSV5-6 DSV6-6 DSV8-6 DSV10-6 #6 #8 #8 #10 1/4 #4 #6 #8 #8 #10 1/4 #8 #10 1/4 5/16 3/8 3.2 3.7 4.3 4.3 5.3 6.5 3.2 3.7 4.3 4.3 5.3 6.5 4.3 5.3 6.5 8.4 10.5 6.0 6.8 8.0 10.0 11.0 5.5 6.0 6.8 8.0 10.0 11.0 8.0 10.0 11.0 14.0 18.0 16.0 17.0 18.0 20.0 18.0 16.0 17.0 19.0 21.0 21.0 22.0 23.0 26.0 28.0 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 500 500 500 500 500 ALL LISTED A.W.G. AMP. 16 18 14 30 12 35 10 50 22 9 20 12 18 17 22-16 A.W.G.: RED 16-14 A.W.G.: BLUE 12-10 A.W.G.: YELLOW INSULATION MATERIAL: VINYL INSULATION COLOR: MAXIMUM ELECTRICAL RATING: 105 C 600 VOLTS MAX. MAXIMUM ELECTRIC CURRENT: TERMINAL MATERIAL: COPPER DIN TERMINALS K. S. TERMINALS INC. 25
WIRE RANGE A.W.G. 2 mm ITEM NO. BUTTED SEAM BRAZED SEAM STUD SIZE DIMENSION mm CRIMPING TOOL Q'TY BOX DRVEB2-1 #2 2.2 1.6 2.3 4.0 4.5 11.2 11.5 0.8 0.8 22-16 A.W.G. 0.5-1.5 2 mm 16-14 A.W.G. 1.5-2.5 2 mm IZUMI MODEL 34 WITH DIE INDEX COLOR:RED OR K.S. MODEL KST2000A HRI-126J KSTLY-2004 KSTLY-2005 WITH DIE INDEX COLOR:RED IZUMI MODEL 34 WITH DIE INDEX COLOR:BLUE OR K.S. MODEL KST2000A HRI-126J KSTLY-2004 KSTLY-2005 WITH DIE INDEX COLOR:BLUE d2 d3 l d1 d4 a S DIN 46237 Equivalent a l d2 d3 S d1 d4 DRVEB2.5-1 DRVEB3-1 DRVEB3.5-1 DRVEBS4-1 DRVEB4-1 DRVEBS5-1 DRVEB5-1 DRVEB6-1 DRVEBL6-1 DRVEB8-1 DRVEB10-1 DRVEBL10-1 DRVEB3-2.5 DRVEB3.5-2.5 DRVEBS4-2.5 DRVEB4-2.5 DRVEBS5-2.5 DRVEB5-2.5 DRVEB6-2.5 DRVEB8-2.5 DRVEB10-2.5 DRVE2-1 DRVE2.5-1 DRVE3-1 DRVE3.5-1 DRVES4-1 DRVE4-1 DRVES5-1 DRVE5-1 DRVE6-1 DRVEL6-1 DRVE8-1 DRVE10-1 DRVEL10-1 DRVE3-2.5 DRVE3.5-2.5 DRVES4-2.5 DRVE4-2.5 DRVES5-2.5 DRVE5-2.5 DRVE6-2.5 DRVE8-2.5 DRVE10-2.5 #3 #4 #6 #8 #8 #10 #10 1/4 1/4 5/16 3/8 3/8 #4 #6 #8 #8 #10 #10 1/4 5/16 3/8 2.7 3.2 3.7 4.3 5.3 6.5 8.4 10.5 3.2 3.7 4.3 5.3 6.5 8.4 10.5 6.0 7.0 8.0 10.0 11.0 14.0 6.0 6.8 8.0 11.0 14.0 15.0 18.0 10.0 17.2 17.7 18.2 19.2 21.2 23.2 17.5 18.1 18.5 22.5 23.5 25.2 20.5 18.7 20.0 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 4.3 5.3 6.5 10.5 4.3 5.3 DRVEBL10-2.5 DRVEB12-2.5 DRVEL10-2.5 DRVE12-2.5 3/8 1/2 10.5 13.0 18.0 1000 1000 25.0 26.5 2.3 4.5 11.5 0.8 K.S. MODEL KST2000A HRI-126J KSTLY-2004 KSTLY-2005 WITH DIE INDEX COLOR:BLUE ALL LISTED A.W.G. AMP. 16 18 14 30 22 9 20 12 18 17 22-16 A.W.G.: RED 16-14 A.W.G.: BLUE INSULATION MATERIAL: VINYL INSULATION COLOR: MAXIMUM ELECTRICAL RATING: 75 C 600 VOLTS MAX. MAXIMUM ELECTRIC CURRENT: TERMINAL MATERIAL: COPPER DIN TERMINALS K. S. TERMINALS INC. 26
WIRE RANGE A.W.G. 2 mm ITEM NO. BUTTED SEAM BRAZED SEAM STUD SIZE DIMENSION mm CRIMPING TOOL Q'TY BOX d2 d3 l d1 d4 a S DIN 46237 Equivalent a l d2 d3 S d1 d4 3.6 6.3 14.1 1.0 12-10 A.W.G. 2 2.5-6 mm IZUMI MODEL 5 WITH DIE INDEX COLOR:YELLOW OR K.S. MODEL KST2000A HRI-126J KSTLY-2004 KSTLY-2005 WITH DIE INDEX COLOR:YELLOW DRVEB4-6 DRVEB5-6 DRVEB6-6 DRVEB8-6 DRVEB10-6 DRVEB12-6 DRVE4-6 DRVE5-6 DRVE6-6 DRVE8-6 DRVE10-6 DRVE12-6 #8 #10 1/4 5/16 3/8 1/2 4.3 5.3 6.5 8.4 10.5 13.0 8.0 10.0 11.0 14.0 18.0 22.1 23.1 24.1 27.1 29.1 500 500 500 500 500 500 ALL LISTED A.W.G. AMP. 12 35 10 50 16-14 A.W.G.: BLUE 12-10 A.W.G.: YELLOW INSULATION MATERIAL: VINYL INSULATION COLOR: MAXIMUM ELECTRICAL RATING: 75 C 600 VOLTS MAX. MAXIMUM ELECTRIC CURRENT: TERMINAL MATERIAL: COPPER DIN TERMINALS K. S. TERMINALS INC. 27
WIRE RANGE A.W.G. 2 mm ITEM NO. BUTTED SEAM BRAZED SEAM STUD SIZE DIMENSION mm CRIMPING TOOL Q'TY BOX DSVEB3-1 #4 3.2 1.6 3.6 2.3 4.0 6.3 4.5 11.2 14.1 11.5 0.8 1.0 0.8 22-16 A.W.G. 0.5-1.5 2 mm 16-14 A.W.G. 1.5-2.5 2 mm 12-10 A.W.G. 2.5-6 2 mm IZUMI MODEL 5 WITH DIE INDEX COLOR:YELLOW OR K.S. MODEL KST2000A HRI-126J WITH DIE INDEX COLOR:YELLOW IZUMI MODEL 34 WITH DIE INDEX COLOR:BLUE OR K.S. MODEL KST2000A HRI-126J WITH DIE INDEX COLOR:BLUE IZUMI MODEL 34 WITH DIE INDEX COLOR:RED OR K.S. MODEL KST2000A HRI-126J WITH DIE INDEX COLOR:RED d2 d3 l d1 d4 a S DIN 46237 Equivalent S d2 d3 a l d1 d4 DSVEB3.5-1 DSVEB4-1 DSVEBL4-1 DSVEB5-1 DSVEB6-1 DSVEB3-2.5 DSVEB3.5-2.5 DSVEB4-2.5 DSVEBL4-2.5 DSVEB5-2.5 DSVEB6-2.5 DSVEB4-6 DSVEB5-6 DSVEB6-6 DSVEB8-6 DSVEB10-6 DSVE3-1 DSVE3.5-1 DSVE4-1 DSVEL4-1 DSVE5-1 DSVE6-1 DSVE3-2.5 DSVE3.5-2.5 DSVE4-2.5 DSVEL4-2.5 DSVE5-2.5 DSVE6-2.5 DSVE4-6 DSVE5-6 DSVE6-6 DSVE8-6 DSVE10-6 #6 #8 #8 #10 1/4 #4 #6 #8 #8 #10 1/4 #8 #10 1/4 5/16 3/8 3.7 4.3 5.3 6.5 3.2 3.7 4.3 5.3 6.5 4.3 5.3 6.5 8.4 10.5 6.0 8.0 6.8 10.0 11.0 5.5 6.0 6.8 10.0 11.0 8.0 10.0 11.0 14.0 18.0 8.0 17.2 18.2 19.2 21.2 19.5 17.5 20.5 22.5 22.1 23.1 24.1 27.1 29.1 18.5 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 500 500 500 500 500 4.3 4.3 ALL LISTED A.W.G. AMP. 16 18 14 30 12 35 10 50 22 9 20 12 18 17 22-16 A.W.G.: RED 16-14 A.W.G.: BLUE 12-10 A.W.G.: YELLOW INSULATION MATERIAL: VINYL INSULATION COLOR: MAXIMUM ELECTRICAL RATING: 75 C 600 VOLTS MAX. MAXIMUM ELECTRIC CURRENT: TERMINAL MATERIAL: COPPER DIN TERMINALS K. S. TERMINALS INC. 28
WIRE RANGE A.W.G. 2 mm ITEM NO. BUTTED SEAM BRAZED SEAM STUD SIZE DIMENSION mm CRIMPING TOOL Q'TY BOX DRNYB2-0.5 #2 2.2 1.0 1.6 2.3 2.3 4.0 4.5 8.0 11.0 11.0 0.5 0.8 0.8 22-16 A.W.G. 0.5-1.5 2 mm 26-22 A.W.G. 0.2-0.5 2 mm 16-14 A.W.G. 1.5-2.5 2 mm K.S. MODEL LY8-067 WITH DIE INDEX NO:0.5 IZUMI MODEL 34 WITH DIE INDEX COLOR:RED OR K.S. MODEL KST2000A HRI-126J WITH DIE INDEX COLOR:RED d2 d3 l d1 d4 a S DIN 46237 Equivalent S d3 d2 a l d1 d4 DRNYB2.5-0.5 DRNYB3-0.5 DRNYB3.5-0.5 DRNYB4-0.5 DRNYB5-0.5 DRNYB2-1 DRNYB2.5-1 DRNYB3-1 DRNYB3.5-1 DRNYBS4-1 DRNYB4-1 DRNYBS5-1 DRNYB5-1 DRNYB6-1 DRNYBL6-1 DRNYB8-1 DRNYB10-1 DRNYBL10-1 DRNYB3-2.5 DRNYB3.5-2.5 DRNYBS4-2.5 DRNY2-0.5 DRNY2.5-0.5 DRNY3-0.5 DRNY3.5-0.5 DRNY4-0.5 DRNY5-0.5 DRNY2-1 DRNY2.5-1 DRNY3-1 DRNY3.5-1 DRNYS4-1 DRNY4-1 DRNYS5-1 DRNY5-1 DRNY6-1 DRNYL6-1 DRNY8-1 DRNY10-1 DRNYL10-1 DRNY3-2.5 DRNY3.5-2.5 DRNYS4-2.5 #3 #4 #6 #8 #10 #2 #3 #4 #6 #8 #8 #10 #10 1/4 1/4 5/16 3/8 3/8 #4 #6 #8 2.7 3.2 3.7 4.3 5.3 2.2 2.7 3.2 3.7 4.3 5.3 6.5 8.4 10.5 3.2 3.7 4.3 5.0 6.0 6.5 8.0 6.0 8.0 10.0 11.0 14.0 18.0 6.0 6.8 7.0 14.0 16.0 17.0 18.0 19.0 21.0 23.0 25.0 17.0 17.6 17.5 18.5 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 4.3 5.3 6.5 10.5 ALL LISTED A.W.G. AMP. 20 12 18 17 16 18 14 30 26 5.5 24 7 22 9 26-22 A.W.G.: YELLOW 22-16 A.W.G.: RED 16-14 A.W.G.: BLUE INSULATION MATERIAL: NYLON INSULATION COLOR: MAXIMUM ELECTRICAL RATING: 105 C 600 VOLTS MAX. MAXIMUM ELECTRIC CURRENT: TERMINAL MATERIAL: COPPER DIN TERMINALS K. S. TERMINALS INC. 29
DIN 46237 Equivalent S d3 d2 a l d1 d4 WIRE RANGE A.W.G. 2 mm ITEM NO. BUTTED SEAM BRAZED SEAM STUD SIZE CRIMPING TOOL Q'TY BOX DRNYB12-2.5 DRNY12-2.5 13.0 18.0 26.0 2.3 3.6 4.5 4.5 6.4 8.0 11.0 13.0 16.5 0.8 1.0 1.1 12-10 A.W.G. 2 2.5-6 mm 16-14 A.W.G. 1.5-2.5 2 mm 8 A.W.G. 2 10 mm IZUMI MODEL 34 WITH DIE INDEX COLOR:BLUE OR K.S. MODEL KST2000A HRI-126J WITH DIE INDEX COLOR:BLUE IZUMI MODEL 5 WITH DIE INDEX COLOR:YELLOW OR K.S. MODEL KST2000A HRI-126J WITH DIE INDEX COLOR:YELLOW KLAUKE MODEL PK25/2 WITH DIE INDEX NO: HIS 25/10 OR K.S. MODEL KST-HDC38A WITH DIE INDEX NO.:8(INS) d2 d3 l d1 d4 a S DIMENSION mm DRNYB12-10 1/2 13.0 22.0 31.5 DRNYB5-10 DRNYB6-10 DRNYB8-10 DRNYB10-10 500 500 500 500 500 #10 1/4 5/16 3/8 5.3 6.5 8.4 10.5 10.0 11.0 14.0 18.0 24.5 25.5 28.5 29.5 DRNYB12-6 DRNY12-6 1/2 13.0 18.0 28.0 DRNYB4-6 DRNYB5-6 DRNYB6-6 DRNYB8-6 DRNYB10-6 DRNY4-6 DRNY5-6 DRNY6-6 DRNY8-6 DRNY10-6 500 500 500 500 500 500 21.0 22.0 23.0 26.0 8.0 10.0 11.0 14.0 4.3 5.3 6.5 8.4 10.5 #8 #10 1/4 5/16 3/8 DRNYB4-2.5 DRNYBS5-2.5 DRNYB5-2.5 DRNYB6-2.5 DRNYB8-2.5 DRNYB10-2.5 DRNYBL10-2.5 DRNY4-2.5 DRNYS5-2.5 DRNY5-2.5 DRNY6-2.5 DRNY8-2.5 DRNY10-2.5 DRNYL10-2.5 1000 1000 1000 1000 1000 1000 1000 1000 #8 #10 #10 1/4 5/16 3/8 3/8 1/2 4.3 5.3 6.5 8.4 10.5 10.5 8.0 10.0 11.0 14.0 15.0 18.0 19.5 20.0 22.0 23.0 24.5 5.3 : NOT UL AND C-UL LISTED ALL LISTED A.W.G. AMP. 10 50 8 70 16 18 14 30 12 35 16-14 A.W.G.: BLUE 12-10 A.W.G.: YELLOW 8 A.W.G.: RED INSULATION MATERIAL: NYLON INSULATION COLOR: MAXIMUM ELECTRICAL RATING: 105 C 600 VOLTS MAX. MAXIMUM ELECTRIC CURRENT: TERMINAL MATERIAL: COPPER DIN TERMINALS K. S. TERMINALS INC. 30
WIRE RANGE A.W.G. 2 mm ITEM NO. BUTTED SEAM BRAZED SEAM STUD SIZE CRIMPING TOOL Q'TY BOX DRNYB5-16 #10 5.3 5.8 7.5 9.0 11.0 11.0 13.0 14.5 16.5 21.5 24.0 27.0 29.5 1.2 1.5 1.6 1.8 4 A.W.G. 2 25 mm 6 A.W.G. 2 16 mm 2 A.W.G. 2 35 mm 1/0 A.W.G. 2 50 mm d2 d3 l d1 d4 a S DIN 46237 Equivalent KLAUKE MODEL PK25/2 WITH DIE INDEX NO: HIS 25/16 OR K.S. MODEL KST-HDC38A WITH DIE INDEX NO.:14(INS) KLAUKE MODEL PK25/2 WITH DIE INDEX NO: HIS 25/25 OR K.S. MODEL KST-HDC38A WITH DIE INDEX NO.:22(INS) KLAUKE MODEL PK25/2 WITH DIE INDEX NO: HIS 25/35 OR K.S. MODEL KST-HDC38A WITH DIE INDEX NO.:38(INS) KLAUKE MODEL PK25/2 WITH DIE INDEX NO: HIS 25/50 DIMENSION mm S d3 d2 a l d1 d4 DRNYB6-16 DRNYB8-16 DRNYB10-16 DRNYB12-16 DRNYB5-25 DRNYB6-25 DRNYB8-25 DRNYB10-25 DRNYB12-25 DRNYB16-25 DRNYB6-35 DRNYB8-35 DRNYB10-35 DRNYB12-35 DRNYB16-35 DRNYB6-50 DRNYB8-50 DRNYB10-50 DRNYB12-50 DRNYB16-50 1/4 5/16 3/8 1/2 #10 1/4 5/16 3/8 1/2 5/8 1/4 5/16 3/8 1/2 5/8 1/4 5/16 3/8 1/2 5/8 6.5 8.4 10.5 13.0 5.3 6.5 8.4 10.5 13.0 17.0 6.5 8.4 10.5 13.0 17.0 6.5 8.4 10.5 13.0 17.0 11.0 14.0 18.0 22.0 12.0 16.0 18.0 22.0 28.0 15.0 16.0 18.0 22.0 28.0 18.0 22.0 28.0 31.5 33.5 35.5 37.5 38.0 39.0 44.0 48.0 41.0 42.0 46.0 51.0 47.5 49.5 53.5 250 250 250 250 250 100 100 100 100 100 100 100 100 100 100 100 50 50 50 50 50 ALL LISTED A.W.G. AMP. 1/0 230 6 95 4 125 2 170 6 A.W.G.: BLUE 4 A.W.G.: YELLOW 2 A.W.G.: RED 1/0 A.W.G.: BLUE INSULATION MATERIAL: NYLON INSULATION COLOR: MAXIMUM ELECTRICAL RATING: 105 C 600 VOLTS MAX. MAXIMUM ELECTRIC CURRENT: TERMINAL MATERIAL: COPPER DIN TERMINALS K. S. TERMINALS INC. 31
WIRE RANGE A.W.G. 2 mm ITEM NO. BUTTED SEAM BRAZED SEAM STUD SIZE CRIMPING TOOL Q'TY BOX DRNYB6-70 1/4 13.0 15.0 16.5 19.0 18.7 21.7 24.2 27.2 31.5 35.5 40.0 44.0 2.0 2.5 3.0 3.2 2/0 A.W.G. 2 70 mm 3/0 A.W.G. 2 95 mm 4/0 A.W.G. 2 120 mm 250/300 MCM 2 150 mm d2 d3 l d1 d4 a S DIN 46237 Equivalent S d3 d2 a l d1 d4 KLAUKE MODEL PK25/2 WITH DIE INDEX NO: HIS 25/70 KLAUKE MODEL PK25/2 WITH DIE INDEX NO: HIS 25/95 KLAUKE MODEL PK25/2 WITH DIE INDEX NO: HIS 25/120 KLAUKE MODEL PK25/2 WITH DIE INDEX NO: HIS 25/150 DIMENSION mm DRNYB8-70 DRNYB10-70 DRNYB12-70 DRNYB16-70 DRNYB8-95 DRNYB10-95 DRNYB12-95 DRNYB16-95 DRNYB8-120 DRNYB10-120 DRNYB12-120 DRNYB16-120 DRNYB10-150 DRNYB12-150 DRNYB16-150 5/16 3/8 1/2 5/8 5/16 3/8 1/2 5/8 5/16 3/8 1/2 5/8 3/8 1/2 5/8 6.5 8.4 10.5 13.0 17.0 8.4 10.5 13.0 17.0 8.4 10.5 13.0 17.0 10.5 13.0 17.0 22.0 28.0 24.0 28.0 24.0 28.0 30.0 51.0 55.0 57.5 59.5 62.0 66.0 70.0 50 50 50 50 50 50 50 25 25 50 25 25 25 25 25 25 ALL LISTED A.W.G. AMP. 250 405 300 445 2/0 265 3/0 310 4/0 360 2/0 A.W.G.: YELLOW 3/0 A.W.G.: RED 4/0 A.W.G.: BLUE INSULATION MATERIAL: NYLON TERMINAL MATERIAL: COPPER INSULATION COLOR: MAXIMUM ELECTRICAL RATING: 105 C 600 VOLTS MAX. MAXIMUM ELECTRIC CURRENT: 250/300 MCM A.W.G.: YELLOW DIN TERMINALS K. S. TERMINALS INC. 32
WIRE RANGE A.W.G. 2 mm ITEM NO. BUTTED SEAM BRAZED SEAM STUD SIZE CRIMPING TOOL Q'TY BOX DSNYB2-0.5 #2 2.2 1.0 1.6 2.3 3.6 2.3 4.0 4.5 6.4 8.0 11.0 11.0 13.0 0.5 0.8 0.8 1.0 22-16 A.W.G. 0.5-1.5 2 mm 26-22 A.W.G. 0.2-0.5 2 mm 16-14 A.W.G. 1.5-2.5 2 mm 12-10 A.W.G. 2 2.5-6 mm d2 d3 l d1 d4 a S K.S. MODEL LY8-067 WITH DIE INDEX NO:0.5 IZUMI MODEL 34 WITH DIE INDEX COLOR:RED OR K.S. MODEL KST2000A HRI-126J WITH DIE INDEX COLOR:RED IZUMI MODEL 34 WITH DIE INDEX COLOR:BLUE OR K.S. MODEL KST2000A HRI-126J WITH DIE INDEX COLOR:BLUE IZUMI MODEL 5 WITH DIE INDEX COLOR:YELLOW OR K.S. MODEL KST2000A HRI-126J WITH DIE INDEX COLOR:YELLOW DIN 46237 Equivalent DIMENSION mm d2 d3 S a l d1 d4 DSNYB3-0.5 DSNYB3.5-0.5 DSNYB4-0.5 DSNYB5-0.5 DSNYB3-1 DSNYB3.5-1 DSNYB4-1 DSNYBL4-1 DSNYB5-1 DSNYB6-1 DSNYB3-2.5 DSNYB3.5-2.5 DSNYB4-2.5 DSNYBL4-2.5 DSNYB5-2.5 DSNYB6-2.5 DSNYB4-6 DSNYB5-6 DSNYB6-6 DSNYB8-6 DSNYB10-6 DSNY2-0.5 DSNY3-0.5 DSNY3.5-0.5 DSNY4-0.5 DSNY5-0.5 DSNY3-1 DSNY3.5-1 DSNY4-1 DSNYL4-1 DSNY5-1 DSNY6-1 DSNY3-2.5 DSNY3.5-2.5 DSNY4-2.5 DSNYL4-2.5 DSNY5-2.5 DSNY6-2.5 DSNY4-6 DSNY5-6 DSNY6-6 DSNY8-6 DSNY10-6 #4 #6 #8 #10 #4 #6 #8 #8 #10 1/4 #4 #6 #8 #8 #10 1/4 #8 #10 1/4 5/16 3/8 3.2 3.7 4.3 5.3 3.2 3.7 4.3 5.3 6.5 3.2 3.7 4.3 5.3 6.5 4.3 5.3 6.5 8.4 10.5 5.0 6.0 6.5 8.0 6.0 6.8 8.0 10.0 11.0 5.5 6.0 8.0 10.0 11.0 8.0 10.0 11.0 14.0 18.0 6.8 12.0 15.0 17.0 18.0 19.0 21.0 19.0 17.0 18.0 20.0 22.0 21.0 22.0 23.0 26.0 28.0 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 500 500 500 500 500 4.3 4.3 ALL LISTED A.W.G. AMP. 20 12 18 17 26 5.5 24 7 22 9 12 35 10 50 16 18 14 30 26-22 A.W.G.: YELLOW 22-16 A.W.G.: RED 16-14 A.W.G.: BLUE INSULATION MATERIAL: NYLON TERMINAL MATERIAL: COPPER INSULATION COLOR: MAXIMUM ELECTRICAL RATING: 105 C 600 VOLTS MAX. MAXIMUM ELECTRIC CURRENT: 12-10 A.W.G.: YELLOW DIN TERMINALS K. S. TERMINALS INC. 33
WIRE RANGE A.W.G. 2 mm ITEM NO. BUTTED SEAM BRAZED SEAM STUD SIZE CRIMPING TOOL Q'TY BOX DRNIB2-1 #2 2.2 1.6 2.3 4.0 4.5 11.0 11.0 0.8 0.8 22-16 A.W.G. 0.5-1.5 2 mm d2 d3 l d1 d4 a S IZUMI MODEL 34 WITH DIE INDEX COLOR:RED OR K.S. MODEL KST2000A WITH DIE INDEX COLOR:RED IZUMI MODEL 34 WITH DIE INDEX COLOR:BLUE OR K.S. MODEL KST2000A WITH DIE INDEX COLOR:BLUE 16-14 A.W.G. 1.5-2.5 2 mm DIN 46237 Equivalent DIMENSION mm d2 S a l d1 d4 d3 DRNIB2.5-1 DRNIB3-1 DRNIB3.5-1 DRNIBS4-1 DRNIB4-1 DRNIBS5-1 DRNIB5-1 DRNIB6-1 DRNIBL6-1 DRNIB8-1 DRNIB10-1 DRNIBL10-1 DRNIB3-2.5 DRNIB3.5-2.5 DRNIBS4-2.5 DRNIB4-2.5 DRNIBS5-2.5 DRNIB5-2.5 DRNIB6-2.5 DRNIB8-2.5 DRNIB10-2.5 DRNI2-1 DRNI2.5-1 DRNI3-1 DRNI3.5-1 DRNIS4-1 DRNI4-1 DRNIS5-1 DRNI5-1 DRNI6-1 DRNIL6-1 DRNI8-1 DRNI10-1 DRNIL10-1 DRNI3-2.5 DRNI3.5-2.5 DRNIS4-2.5 DRNI4-2.5 DRNIS5-2.5 DRNI5-2.5 DRNI6-2.5 DRNI8-2.5 DRNI10-2.5 #3 #4 #6 #8 #8 #10 #10 1/4 1/4 5/16 3/8 3/8 #4 #6 #8 #8 #10 #10 1/4 5/16 3/8 2.7 3.2 3.7 4.3 5.3 6.5 8.4 10.5 3.2 3.7 4.3 5.3 6.5 8.4 10.5 6.0 7.0 8.0 8.0 11.0 14.0 18.0 6.0 6.8 8.0 11.0 14.0 15.0 10.0 10.0 17.0 17.5 18.0 18.5 21.0 23.0 25.0 17.0 17.6 18.0 22.0 23.0 19.0 20.0 19.5 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 4.3 5.3 6.5 10.5 4.3 5.3 DRNIBL10-2.5 DRNIB12-2.5 DRNIL10-2.5 DRNI12-2.5 3/8 1/2 10.5 13.0 18.0 1000 1000 24.5 26.0 ALL LISTED A.W.G. AMP. 20 12 18 17 22 9 16 18 14 30 22-16 A.W.G.: RED 16-14 A.W.G.: BLUE INSULATION MATERIAL: PC INSULATION COLOR: MAXIMUM ELECTRICAL RATING: 125 C 600 VOLTS MAX. MAXIMUM ELECTRIC CURRENT: TERMINAL MATERIAL: COPPER DIN TERMINALS K. S. TERMINALS INC. 34
WIRE RANGE A.W.G. 2 mm ITEM NO. BUTTED SEAM BRAZED SEAM STUD SIZE CRIMPING TOOL Q'TY BOX d2 d3 l d1 d4 a S DIN 46237 Equivalent DIMENSION mm S a l d1 d4 d3 3.6 6.4 13.0 1.0 12-10 A.W.G. 2.5-6 2 mm IZUMI MODEL 5 WITH DIE INDEX COLOR:YELLOW OR K.S. MODEL KST2000A WITH DIE INDEX COLOR:YELLOW DRNIB4-6 DRNIB5-6 DRNIB6-6 DRNIB8-6 DRNIB10-6 DRNIB12-6 DRNI4-6 DRNI5-6 DRNI6-6 DRNI8-6 DRNI10-6 DRNI12-6 #8 #10 1/4 5/16 3/8 1/2 4.3 5.3 6.5 8.4 10.5 13.0 8.0 10.0 11.0 14.0 18.0 21.0 22.0 23.0 26.0 28.0 500 500 500 500 500 500 ALL LISTED A.W.G. AMP. 12 35 10 50 16-14 A.W.G.: BLUE 12-10 A.W.G.: YELLOW INSULATION MATERIAL: PC INSULATION COLOR: MAXIMUM ELECTRICAL RATING: 125 C 600 VOLTS MAX. MAXIMUM ELECTRIC CURRENT: TERMINAL MATERIAL: COPPER DIN TERMINALS K. S. TERMINALS INC. 35
WIRE RANGE A.W.G. 2 mm ITEM NO. BUTTED SEAM BRAZED SEAM STUD SIZE CRIMPING TOOL Q'TY BOX DSNIB3-1 #4 1.6 2.3 4.0 4.5 11.0 11.0 0.8 0.8 22-16 A.W.G. 0.5-1.5 2 mm d2 d3 l d1 d4 a S 16-14 A.W.G. 1.5-2.5 2 mm 3.6 6.4 13.0 1.0 IZUMI MODEL 34 WITH DIE INDEX COLOR:RED OR K.S. MODEL KST2000A WITH DIE INDEX COLOR:RED IZUMI MODEL 34 WITH DIE INDEX COLOR:BLUE OR K.S. MODEL KST2000A WITH DIE INDEX COLOR:BLUE IZUMI MODEL 5 WITH DIE INDEX COLOR:YELLOW OR K.S. MODEL KST2000A WITH DIE INDEX COLOR:YELLOW 12-10 A.W.G. 2.5-6 2 mm DIN 46237 Equivalent DIMENSION mm d2 d3 S a l d1 d4 DSNIB3.5-1 DSNIB4-1 DSNIBL4-1 DSNIB5-1 DSNIB6-1 DSNIB3-2.5 DSNIB3.5-2.5 DSNIB4-2.5 DSNIBL4-2.5 DSNIB5-2.5 DSNIB6-2.5 DSNIB4-6 DSNIB5-6 DSNIB6-6 DSNIB8-6 DSNIB10-6 DSNI3-1 DSNI3.5-1 DSNI4-1 DSNIL4-1 DSNI5-1 DSNI6-1 DSNI3-2.5 DSNI3.5-2.5 DSNI4-2.5 DSNIL4-2.5 DSNI5-2.5 DSNI6-2.5 DSNI4-6 DSNI5-6 DSNI6-6 DSNI8-6 DSNI10-6 #6 #8 #8 #10 1/4 #4 #6 #8 #8 #10 1/4 #8 #10 1/4 5/16 3/8 3.2 3.7 4.3 5.3 6.5 3.2 3.7 4.3 5.3 6.5 4.3 5.3 6.5 8.4 10.5 6.0 6.8 8.0 10.0 11.0 5.5 6.0 8.0 10.0 11.0 8.0 10.0 11.0 14.0 18.0 6.8 17.0 18.0 19.0 21.0 19.0 17.0 20.0 22.0 21.0 22.0 23.0 26.0 28.0 18.0 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 1000 500 500 500 500 500 ALL LISTED 4.3 4.3 A.W.G. AMP. 16 18 14 30 22 9 20 12 18 17 12 35 10 50 22-16 A.W.G.: RED 16-14 A.W.G.: BLUE 12-10 A.W.G.: YELLOW INSULATION MATERIAL: PC INSULATION COLOR: MAXIMUM ELECTRICAL RATING: 125 C 600 VOLTS MAX. MAXIMUM ELECTRIC CURRENT: TERMINAL MATERIAL: COPPER DIN TERMINALS K. S. TERMINALS INC. 36
WIRE RANGE A.W.G. 2 mm ITEM NO. EN0206 DIMENSION W L D C DIN 46228 .043 inch mm inch mm inch mm inch mm .236 1.1 .031 0.8 .067 1.7 CRIMPING TOOL .047 1.2 .035 0.9 .071 1.8 .051 1.3 .039 1.0 .083 2.1 .059 1.5 .047 1.2 .091 2.3 K.S. MODEL LY8-060 WITH DIE INDEX NO:0.25-0.75 OR K.S. MODEL KST2000L WITH DIE INDEX NO:0.25 OR K.S. MODEL LY8-060 WITH DIE INDEX NO:0.25-0.75 K.S. MODEL KST2000L WITH DIE INDEX NO:0.75 OR K.S. MODEL LY8-060 WITH DIE INDEX NO:0.25-0.75 24 A.W.G. 2 0.25 mm 22 A.W.G. 2 0.34 mm 20 A.W.G. 2 0.5 mm 18 A.W.G. 2 0.75 mm W L C D EN0207 EN0208 EN0306 EN0307 EN0505 EN0506 EN0508 EN0510 EN0512 .276 .315 .236 .276 .197 .236 .315 .394 .472 .236 .315 .394 .472 .591 .787 6.0 7.0 8.0 6.0 7.0 5.0 6.0 8.0 10.0 12.0 6.0 8.0 10.0 12.0 15.0 20.0 EN0215 EN0225 .591 .984 15.0 25.0 EN0308 .315 8.0 .276 7.0 A.W.G. AMP. 24 7 22 9 26 5.5 20 12 TERMINAL MATERIAL: COPPER TUBE. (TIN PLATED) MAXIMUM ELECTRIC CURRENT: EN7506 EN7508 EN7510 EN7512 EN7515 EN7520 EN7507 EN7505 .197 5.0 EN0305 .197 5.0 EN0205 .197 5.0 K.S. MODEL KST2000L WITH DIE INDEX NO:0.25 ALL LISTED E511742 : NOTRU AND C-RU LISTED EN0310 .394 10.0 37 CORD END TERMINALS K. S. TERMINALS INC.
DIN 46228 WIRE RANGE A.W.G. 2 mm ITEM NO. DIMENSION W L D C inch mm inch mm inch mm inch mm .709 CRIMPING TOOL .079 2.0 .067 1.7 .110 2.8 .102 2.6 .091 2.3 .134 3.4 K.S. MODEL KST2000L WITH DIE INDEX NO:1.5 OR K.S. MODEL LY8-060 WITH DIE INDEX NO:1-1.5 K.S. MODEL KST2000L WITH DIE INDEX NO:2.5 OR K.S. MODEL LY8-060 WITH DIE INDEX NO:2.5 18 A.W.G. 2 1.0 mm 16 A.W.G. 2 1.5 mm 14 A.W.G. 2 2.5 mm EN1018 W L C D EN1020 EN1507 EN1508 EN1510 EN1512 EN1515 EN1518 EN1520 EN2506 EN2507 EN2508 EN2510 EN2512 EN2515 .787 .276 .315 .394 .472 .591 .709 .787 .236 .276 .315 .394 .472 .591 18.0 20.0 7.0 8.0 10.0 12.0 15.0 18.0 20.0 6.0 7.0 8.0 10.0 12.0 15.0 EN1506 .236 6.0 EN1025 .984 25.0 .236 EN1006 EN1007 .276 6.0 7.0 EN1008 .315 8.0 .067 .394 1.7 .055 1.4 .098 2.5 EN1010 EN1012 .472 10.0 12.0 EN1015 .591 15.0 K.S. MODEL KST2000L WITH DIE INDEX NO:1 OR K.S. MODEL LY8-060 WITH DIE INDEX NO:1-1.5 A.W.G. AMP. 16 18 14 30 18 17 TERMINAL MATERIAL: COPPER TUBE. (TIN PLATED) MAXIMUM ELECTRIC CURRENT: ALL LISTED E511742 : NOTRU AND C-RU LISTED CORD END TERMINALS K. S. TERMINALS INC. 38
DIN 46228 W L C D WIRE RANGE A.W.G. 2 mm ITEM NO. DIMENSION W L D C .126 inch mm inch mm inch mm inch mm .709 3.2 .110 2.8 .157 4.0 CRIMPING TOOL .154 3.9 .138 3.5 .185 4.7 K.S. MODEL KST2000M WITH DIE INDEX NO:6 OR K.S. MODEL LY8-060 WITH DIE INDEX NO:6 K.S. MODEL KST2000M WITH DIE INDEX NO:10 12 A.W.G. 2 4 mm 10 A.W.G. 2 6 mm EN4018 EN4020 EN6006 EN6010 EN6012 EN6015 EN6018 EN6020 EN10-12 EN10-15 .787 .236 .394 .472 .591 .709 .787 .472 .591 18.0 20.0 6.0 10.0 12.0 15.0 18.0 20.0 12.0 15.0 EN4030 1.181 30.0 EN6025 .984 25.0 EN10-6 EN10-8 .236 .315 6.0 8.0 .102 .709 2.6 .091 2.3 .134 3.4 EN2518 EN2520 .787 18.0 20.0 EN2525 .984 25.0 1.181 EN2530 30.0 K.S. MODEL KST2000L WITH DIE INDEX NO:2.5 OR K.S. MODEL LY8-060 WITH DIE INDEX NO:2.5 14 A.W.G. 2 2.5 mm .276 EN4007 EN4009 .354 7.0 9.0 EN4010 .394 10.0 .472 EN4012 12.0 .591 EN4015 15.0 K.S. MODEL KST2000L WITH DIE INDEX NO:4 OR K.S. MODEL LY8-060 WITH DIE INDEX NO:4 OR WACO MODEL VARIOCRIMP 4 8 A.W.G. 2 10 mm .193 4.9 .177 4.5 .228 5.8 A.W.G. AMP. 12 35 10 50 14 15 8 70 TERMINAL MATERIAL: COPPER TUBE. (TIN PLATED) MAXIMUM ELECTRIC CURRENT: ALL LISTED E511742 : NOTRU AND C-RU LISTED 39 CORD END TERMINALS K. S. TERMINALS INC.
K.S. MODEL KST2000M WITH DIE INDEX NO:16 6 A.W.G. 2 16 mm EN10-25 EN16-12 EN16-15 EN16-16 .984 .472 .591 .630 25.0 12.0 15.0 16.0 EN16-6 EN16-8 .236 .315 6.0 8.0 .193 4.9 .177 4.5 .228 5.8 8 A.W.G. 2 10 mm EN10-16 EN10-18 .630 .709 16.0 18.0 EN10-20 .787 20.0 W L C D DIN 46228 WIRE RANGE A.W.G. 2 mm ITEM NO. DIMENSION W L D C inch mm inch mm inch mm inch mm CRIMPING TOOL .303 7.7 .287 7.3 .366 9.3 K.S. MODEL KSTP325-B WITH DIE INDEX NO:E-25 4 A.W.G. 2 25 mm EN25-12 EN25-15 EN25-16 EN25-18 EN25-20 EN25-22 .472 .591 .630 .709 .787 .866 12.0 15.0 16.0 18.0 20.0 22.0 EN25-6 EN25-8 .236 .315 6.0 8.0 .244 6.2 .228 5.8 .299 7.6 EN16-22 EN16-25 EN16-30 EN16-32 .866 .984 1.181 1.260 22.0 25.0 30.0 32.0 EN16-18 EN16-20 .709 .787 18.0 20.0 K.S. MODEL KST2000M WITH DIE INDEX NO:10 A.W.G. AMP. 6 95 4 125 8 70 TERMINAL MATERIAL: COPPER TUBE. (TIN PLATED) MAXIMUM ELECTRIC CURRENT: EN25-13 .512 13.0 EN10-22 .866 22.0 ALL LISTED E511742 : NOT RU AND C-RU LISTED : DEVELOPING ON DEMAND 40 CORD END TERMINALS K. S. TERMINALS INC.
.343 8.7 .327 8.3 .425 10.8 K.S. MODEL KSTP325-B WITH DIE INDEX NO:E-35 2 A.W.G. 2 35 mm EN35-12 EN35-15 EN35-16 EN35-18 EN35-20 .472 .591 .630 .709 .787 12.0 15.0 16.0 18.0 20.0 EN25-50 1.969 50.0 EN25-25 EN25-30 EN25-32 .984 1.181 1.260 25.0 30.0 32.0 DIN 46228 W L C D WIRE RANGE A.W.G. 2 mm ITEM NO. DIMENSION W L D C .429 inch mm inch mm inch mm inch mm .984 10.9 .406 10.3 .504 12.8 CRIMPING TOOL .559 14.2 .531 13.5 .622 15.8 K.S. MODEL KSTP325-B WITH DIE INDEX NO:E-50 K.S. MODEL KSTP325-B WITH DIE INDEX NO:KC-70 1/0 A.W.G. 2 50 mm 2/0 A.W.G. 2 70 mm EN50-25 EN50-30 EN50-32 EN70-22 EN70-25 EN70-30 EN70-32 1.181 1.260 .866 .984 1.181 1.260 25.0 30.0 32.0 22.0 25.0 30.0 32.0 .866 EN35-22 EN35-25 EN35-30 .984 1.181 22.0 25.0 30.0 EN35-32 1.260 32.0 .472 EN50-12 EN50-18 EN50-22 .709 .866 12.0 18.0 22.0 K.S. MODEL KSTP325-B WITH DIE INDEX NO:E-25 4 A.W.G. 2 25 mm .303 7.7 .287 7.3 .366 9.3 A.W.G. AMP. 2 170 1/0 230 4 125 2/0 265 TERMINAL MATERIAL: COPPER TUBE. (TIN PLATED) MAXIMUM ELECTRIC CURRENT: EN50-50 1.969 50.0 EN50-20 .787 20.0 41 ALL LISTED E511742 : NOT RU AND C-RU LISTED : DEVELOPING ON DEMAND CORD END TERMINALS K. S. TERMINALS INC.
