ELECTRICAL CONTROL BOX ACCESSORIES SOLUTION K. S. TERMINALS INC.
我們的優勢 Our Advantage 獲得ROHS認證,採用純PA66 Ascend Vydyne 21 SPC原料。 束帶的伸展強度超過業界標準的20%，且柔度韌性好，方便捆紮。 紮帶耐高溫+60℃，耐低溫-20°C。 採用熱流道模俱生產，確保其一致性、穩定性和高品質。 ROHS certificates. Pure pa66 Ascend Vydyne 21 SPC raw material. Cable tie tensile strength exceeds 20% of industry standard and flexible for bundling. Cable tie meets high temperature +60℃ and low temperature -20°C Cable tie are produced by hot runner molds to ensure the consistency,stability and quality. 產品規格 Product Specifications Nylon Cable Ties 01 K. S. TERMINALS INC. 1 CE ROHS L W E 材質: PA66 Material: PA66 ET-80M ET-100M ET-120M 管束直徑 (mm) Bundle diameter ET-300I ET-150M ET-200M ET-150I ET-200I ET-250I ET-350I ET-370I ET-400I ET-450I ET-500I ET-150S ET-180S ET-200S ET-250S ET-300S ET-350S ET-380S ET-400S 產品料號 Item No. 最小抗拉強度 Min.loop tensile strength 寬度 W (mm) 長度 L (mm) 英吋 INCH 毫米 MM 拉伸強度KGS 磅 LBS ET Series - 標準型 Standard Type
產品特點 Product Features ●韌性強，防滑 ●堅固耐用，不易斷裂 ●環保新材料，無毒無害 ●耐老化，堅固耐用 ●耐低溫性能好 ●Toughness, no slip ●Strong and hard to break ●Environmental protection new material,non-toxic ●Aging resistance, strong and durable ●Good low temperature resistance ET Series - 標準型 Standard Type 01 K. S. TERMINALS INC. 2 CE ROHS L W E 材質: PA66 Material: PA66 ET-150SD ET-180SD ET-200SD ET-250SD ET-300SD ET-350SD ET-380SD ET-400SD ET-450SD ET-500SD ET-250H ET-300H ET-350H ET-380H ET-400H ET-450H ET-500H ET-550H ET-400L ET-500L ET-550L ET-600L ET-650L ET-700L ET-760L ET-800L ET-900L ET-1000L ET-1220L ET-1350L ET-1530L 管束直徑 (mm) Bundle diameter 產品料號 Item No. 最小抗拉強度 Min.loop tensile strength 寬度 W (mm) 長度 L (mm) 英吋 INCH 毫米 MM 拉伸強度KGS 磅 LBS Nylon Cable Ties
Stainless Steel Cable Ties 02 K. S. TERMINALS INC. 1 SPSTB Series Stainless Steel Cable Ties-Ball Lock Uncoated Ties Ball-Lock type self-lock system will speed up the installation Material: Stainless Steel Grade 304 or 316 Working Temp: -80℃ to 538 ℃ Description: Entirely metallic Flammability: Fireproof Other Properties: UV-resistant Item No. Max Bundle Dia Ø mm (Inch) "L" Approx Length mm (Inch) Min Loop Tensile (Kg) Bag Quantity 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS "W" Approx Width mm (Inch) Thickness mm (Inch) SPSTB-125S SPSTB-152S SPSTB-200S SPSTB-250S SPSTB-300S SPSTB-360S SPSTB-400S SPSTB-500S SPSTB-520S SPSTB-680S SPSTB-840S SPSTB-1050S SPSTB-152M SPSTB-200M SPSTB-250M SPSTB-300M SPSTB-360M SPSTB-520M SPSTB-680M SPSTB-840M SPSTB-1050M SPSTB-290L SPSTB-360L SPSTB-430L SPSTB-520L SPSTB-600L SPSTB-680L SPSTB-750L SPSTB-840L SPSTB-910L SPSTB-1000L SPSTB-1070L SPSTB-1200L 20(0.79) 25(0.98) 50 (1.97) 60(2.36) 75(2.95) 102(4.02) 108(4.25) 140(5.51) 152(5.98) 203(7.99) 254(10) 318(12.52) 25(0.98) 50(1.97) 60(2.36) 75(2.95) 102(4.02) 152(5.98) 203(7.99) 254(10) 318(12.52) 80(3.15) 102(4.02) 121(4.76) 152(5.98) 175(6.89) 203(7.99) 230(9.06) 254(10) 273(10.75) 302(11.89) 325(12.8) 351(13.82) 125(4.92) 152(5.98) 200(7.87) 250(9.84) 300(11.81) 360(14.17) 400(15.75) 500(19.69) 520(20.47) 680(26.77) 840(33.07) 1050(41.34) 152(5.98) 200(7.87) 250(9.84) 300(11.81) 360(14.17) 520(20.47) 680(26.77) 840(33.07) 1050(41.34) 290(11.42) 360(14.17) 430(16.93) 520(20.47) 600(23.62) 680(26.77) 750(29.53) 840(33.07) 910(35.83) 1000(39.37) 1070(42.13) 1200(47.24) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 7.9(0.31) 7.9(0.31) 7.9(0.31) 7.9(0.31) 7.9(0.31) 7.9(0.31) 7.9(0.31) 7.9(0.31) 7.9(0.31) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.25(0.010) 0.35(0.014) 0.35(0.014) 0.35(0.014) 0.35(0.014) 0.35(0.014) 0.35(0.014) 0.35(0.014) 0.35(0.014) 0.35(0.014) 0.35(0.014) 0.35(0.014) 0.35(0.014) 45.4 45.4 45.4 45.4 45.4 45.4 45.4 45.4 45.4 45.4 45.4 45.4 113.4 113.4 113.4 113.4 113.4 113.4 113.4 113.4 113.4 270 270 270 270 270 270 270 270 270 270 270 270 Standard(Uncoated) T W L
Stainless Steel Cable Ties K. S. TERMINALS INC. 2 SPSTBCE Series Stainless Steel Cable Ties-Ball Lock Epoxy Coated Ties Item No. Max Bundle Dia Ø mm (Inch) "L" Approx Length mm (Inch) Min Loop Tensile (Kg) Bag Quantity 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS 100 PCS "W" Approx Width mm (Inch) Thickness mm (Inch) SPSTBCE-125S SPSTBCE-152S SPSTBCE-200S SPSTBCE-250S SPSTBCE-300S SPSTBCE-360S SPSTBCE-400S SPSTBCE-500S SPSTBCE-520S SPSTBCE-680S SPSTBCE-840S SPSTBCE-1050S SPSTBCE-152M SPSTBCE-200M SPSTBCE-250M SPSTBCE-300M SPSTBCE-360M SPSTBCE-520M SPSTBCE-680M SPSTBCE-840M SPSTBCE-1050M SPSTBCE-290L SPSTBCE-360L SPSTBCE-430L SPSTBCE-520L SPSTBCE-600L SPSTBCE-680L SPSTBCE-750L SPSTBCE-840L SPSTBCE-910L SPSTBCE-1000L SPSTBCE-1070L SPSTBCE-1200L 20(0.79) 25(0.98) 50 (1.97) 60(2.36) 75(2.95) 102(4.02) 108(4.25) 140(5.51) 152(5.98) 203(7.99) 254(10) 318(12.52) 25(0.98) 50(1.97) 60(2.36) 75(2.95) 102(4.02) 152(5.98) 203(7.99) 254(10) 318(12.52) 80(3.15) 102(4.02) 121(4.76) 152(5.98) 175(6.89) 203(7.99) 230(9.06) 254(10) 273(10.75) 302(11.89) 325(12.8) 351(13.82) 125(4.92) 152(5.98) 200(7.87) 250(9.84) 300(11.81) 360(14.17) 400(15.75) 500(19.69) 520(20.47) 680(26.77) 840(33.07) 1050(41.34) 152(5.98) 200(7.87) 250(9.84) 300(11.81) 360(14.17) 520(20.47) 680(26.77) 840(33.07) 1050(41.34) 290(11.42) 360(14.17) 430(16.93) 520(20.47) 600(23.62) 680(26.77) 750(29.53) 840(33.07) 910(35.83) 1000(39.37) 1070(42.13) 1200(47.24) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 4.6(0.18) 7.9(0.31) 7.9(0.31) 7.9(0.31) 7.9(0.31) 7.9(0.31) 7.9(0.31) 7.9(0.31) 7.9(0.31) 7.9(0.31) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 11.8(0.47) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.38(0.015) 0.45(0.018) 0.45(0.018) 0.45(0.018) 0.45(0.018) 0.45(0.018) 0.45(0.018) 0.45(0.018) 0.45(0.018) 0.45(0.018) 0.45(0.018) 0.45(0.018) 0.45(0.018) 45.4 45.4 45.4 45.4 45.4 45.4 45.4 45.4 45.4 45.4 45.4 45.4 113.4 113.4 113.4 113.4 113.4 113.4 113.4 113.4 113.4 270 270 270 270 270 270 270 270 270 270 270 270 Epoxy Coated Fully coated version will prevent from staticelectricity. Polyester coated band provide additional edge protection,prevent the corrosion between dissimilar materials. Material: Stainless Steel Grade 304 or 316 Coating: Polyester/Epoxy, Nylon 11 Working Temp: -80°C to 150°C Flammability: Fireproof Other Properties: UV-resistant, Halogen free, non toxic T W L 02
Cable Markers K. S. TERMINALS INC. 1 SPSMP Series Part NO. “L” Length (mm) “W” Width (mm) “T” Thickness (mm) “C” Cable Slot (mm) SPSMPS-4.5-60x9.5 60 9.5 0.4 5.6 SPSMPS-4.5-70x9.5 70 9.5 0.5 5.6 SPSMPS-4.5-89x9.5 89 9.5 0.4 5.6 SPSMPS-4.5-102x9.5 102 9.5 0.4 5.6 SPSMPM-8.0-110x15 110 15 0.4 9.6 SPSMPM-8.0-60x19 60 19 0.4 10.1 SPSMPM-8.0-89x19 89 19 0.4 10.1 SPSMPM-8.0-110x19 110 19 0.4 10.1 Part NO. “L” Length (mm) “W” Width (mm) “T” Thickness (mm) “C” Cable Slot (mm) Part NO. “L” Length (mm) “W” Width (mm) “T” Thickness (mm) “C” Cable Slot (mm) W L C T W L C T W L C T Material: Stainless Steel 316 03
Corrugated Pipe K. S. TERMINALS INC. 1 SPCR Series 材質：採用高品質聚醯胺/尼龍 (PA) 、聚丙烯 (PP) 製成，阻燃等級 符合 UL94 HB 標準。 工作溫度範圍： 聚醯胺/尼龍 (PA)： –40℃ ~ +115℃（瞬間耐溫可達 +150℃） 聚丙烯 (PP)： –40℃ ~ +110℃（瞬間耐溫可達 +130℃） 顏色：標準供應黑色。 產品特性：優異的防塵與防液體滲入性能；耐油、耐酸、耐溶劑， 適用於嚴苛工業環境，不含鹵素、矽、鎘等有害物質；高柔韌性， 抗彎曲、抗扭曲，表面光澤佳，具優良耐磨耗性能，高機械強度 與耐衝擊性，黑色款具優異抗紫外線（UV）性能，適合戶外使用。 應用範圍：廣泛應用於工業電氣設備配線保護，提供絕緣、隔熱及 機械防護功能，適用於自動化設備、控制系統、配電裝置及各類 電氣安裝工程。 我們的優勢 Our Advantage - 波紋管 Material Manufactured from high-quality Polyamide (PA), or Polypropylene (PP). Flame retardant rating complies with UL94 HB standards. Operating Temperature Range Polyamide (PA): –40°C to +115°C (short-term resistance up to +100°C) Polypropylene (PP): –40°C to +110°C (short-term resistance up to +130°C) Color Standard colors: Black and Gray. Custom colors available upon request. Product Features Excellent resistance to dust and liquid ingress; oil-resistant, acid-resistant, and solvent-resistant. Suitable for harsh industrial environments. Free from halogens, silicone, cadmium, and other hazardous substances. High flexibility with superior resistance to bending and twisting. Smooth surface finish with excellent abrasion resistance. High mechanical strength and impact resistance. Black version provides outstanding UV resistance, making it suitable for outdoor applications. Applications Widely used for wiring protection in industrial electrical equipment, providing insulation, thermal protection, and mechanical protection. Suitable for automation equipment, control systems, power distribution devices, and various electrical installation projects. 04
Corrugated Pipe K. S. TERMINALS INC. 2 SPCR Series 產品規格 Product Specifications 產品料號 Item No. 內 徑(d) (mm) 外 徑(D) (mm) 每捲長度 Length per Roll (m) 材 質 Material SPCR10-PA 靜態彎曲半徑 Static Bending Radius (mm) 動態彎曲半徑 Dynamic Bending Radius (mm) 6.5 10 14 35 100 PA SPCR11.6-PA 8 11.6 17 40 100 PA SPCR13-PA 9.5 13 20 45 100 PA SPCR18.5-PA 14.3 35 65 100 PA SPCR15.8-PA 12 15.8 27 55 100 PA 18.5 SPCR25.5-PA 43 85.5 100 PA 25.5 SPCR21.2-PA 17 21.2 40 75 100 PA 21 SPCR28.5-PA 23 28.5 47 100 50 PA SPCR34.5-PA 29 34.5 58 120 50 PA SPCR42.5-PA 36 42.5 69 150 50 PA SPCR54.5-PA 48 54.5 83 190 25 PA SPCR10-PP 6.5 10 16 37 100 PP SPCR11.6-PP 8 11.6 18 43 100 PP SPCR13-PP 9.5 13 21 48 100 PP SPCR18.5-PP 14.3 37 70 100 PP SPCR15.8-PP 12 15.8 26 56 100 PP 18.5 SPCR25.5-PP 49 88 100 PP 25.5 SPCR21.2-PP 17 21.2 44 79 100 PP 21 SPCR28.5-PP 23 28.5 52 104 50 PP SPCR34.5-PP 29 34.5 58 123 50 PP SPCR42.5-PP 36 42.5 68 152 50 PP SPCR54.5-PP 48 54.5 84 193 25 PP 材質：聚醯胺/尼龍 (PA) / 聚丙烯 (PP) 阻燃等級HB，參照UL94 Material: Polyamide (PA) / polypropylene (PP) / HB according to UL 94 04
Expand Plugs K. S. TERMINALS INC. 1 SPEN、SPRT Series 膨脹管 RT型膨脹管 長型膨脹管 產品料號 Item No. 內 徑(d) (mm) 外 徑(D) (mm) 螺絲釘 Screw (mm) 長(L) (mm) SPEN-06 x 30 SPEN-07 x 30 SPEN-08 x 40 SPEN-08 x 80 SPEN-10 x 45 SPEN-10 x 100 SPEN-12 x 50 SPEN-12 x 60 SPEN-14 x 70 SPRT-06 x 30 SPRT-06 x 50 SPRT-07 x 35 SPRT-08 x 40 SPRT-08 x 65 SPRT-10 x 50 SPRT-10 x 80 SPRT-12 x 60 SPRT-14 x 70 內 徑(d) (mm) 外 徑(D) (mm) 螺絲釘 Screw (mm) 長(L) (mm) SPEN-08L SPEN-10L 產品料號 Item No. 內 徑(d) (mm) 外 徑(D) (mm) 螺絲釘 Screw (mm) 長(L) (mm) 產品料號 Item No. SPEN-06 x 30-GY SPEN-07 x 30-GY SPEN-08 x 40-GY SPEN-08 x 80-GY SPEN-10 x 45-GY SPEN-10 x 100-GY SPEN-12 x 50-GY SPEN-12 x 60-GY SPEN-14 x 70-GY SPRT-06 x 30-GY SPRT-06 x 50-GY SPRT-07 x 35-GY SPRT-08 x 40-GY SPRT-08 x 65-GY SPRT-10 x 50-GY SPRT-10 x 80-GY SPRT-12 x 60-GY SPRT-14 x 70-GY SPEN-08L-GY SPEN-10L-GY 05
Spiral Wrapping Bands K. S. TERMINALS INC. 1 SPSW Series 卷式結束保護帶(纏繞管) 產品規格 Product Specifications 材質：採用優質聚乙烯 (PE) 製成。 安裝：將螺旋纏繞帶的一端固定在起始點，然後按順時針方向環繞 束緊在電纜束上為一體，使其緊密整齊地固定。 應用：旨在保護電線和電纜束免受磨損和損壞，同時提供絕緣。 改善電纜管理，提升佈線系統的整體美觀。 Material Manufactured from high-quality Polyethylene (PE). Installation Secure one end of the spiral wrap to the starting point, then wind it clockwise around the cable bundle to achieve a tight and organized fit. Applications Designed to protect electrical wires and cable bundles from abrasion and damage while providing insulation. Improves cable management and enhances the overall appearance of wiring systems. 產品料號 Item No. 內 徑(d) (mm) 外 徑(D) (mm) 螺 距(W) (mm) 捆紮範圍 Wrapping Range (mm) 包 裝 Packing SPSW-03 SPSW-06 SPSW-08 SPSW-10 SPSW-12 SPSW-15 SPSW-19 SPSW-24 SPSW-30 06
Wiring Duct K. S. TERMINALS INC. 1 SPWD Series HxW Thickness SPWD-2015 SPWD-2020 SPWD-2025 SPWD-2525 SPWD-2540 SPWD-2545 SPWD-2560 SPWD-2580 SPWD-3015 SPWD-3020 SPWD-3025 SPWD-3030 SPWD-3035 SPWD-3040 SPWD-3050 SPWD-3525 SPWD-3530 SPWD-3535 SPWD-4025 SPWD-4030 SPWD-4035 SPWD-4040 SPWD-4060 SPWD-4080 07
HxW Thickness SPWD-4525 SPWD-4535 SPWD-4545 SPWD-4565 SPWD-5015 SPWD-5025 SPWD-5030 SPWD-5035 SPWD-5040 SPWD-5045 SPWD-5050 SPWD-5055 SPWD-5060 SPWD-5080 SPWD-50100 SPWD-6025 SPWD-6040 SPWD-6060 SPWD-6080 SPWD-60100 SPWD-6525 SPWD-6545 SPWD-6565 SPWD-7550 SPWD-8025 SPWD-8035 SPWD-8040 SPWD-8045 SPWD-8050 SPWD-8055 SPWD-8060 SPWD-8080 SPWD-80100 SPWD-10033 SPWD-10040 SPWD-10050 SPWD-10060 SPWD-10080 SPWD-100100 SPWD-130100 Wiring Duct K. S. TERMINALS INC. 2 07
Cable Glands K. S. TERMINALS INC. 1 SPPG Series SPPG-N07 SPPG-N09 SPPG-N11 SPPG-N13.5 SPPG-N16 SPPG-N19 SPPG-N21 SPPG-N24 SPPG-N29 SPPG-N36 SPPG-N42 SPPG-N48 SPPG-N63 SPPG-N07-NS SPPG-N09-NS SPPG-N11-NS SPPG-N13.5-NS SPPG-N16-NS SPPG-N19-NS SPPG-N21-NS SPPG-N24-NS SPPG-N29-NS SPPG-N36-NS SPPG-N42-NS SPPG-N48-NS SPPG-N63-NS ※-NS：Without Seal 08
Cable Glands K. S. TERMINALS INC. 2 SPMG Series SPMG-12-BLACK SPMG-16-BLACK SPMG-20-BLACK SPMG-25-BLACK SPMG-32-BLACK SPMG-40-BLACK SPMG-50-BLACK SPMG-63-BLACK SPMG-12-GREY SPMG-16-GREY SPMG-20-GREY SPMG-25-GREY SPMG-32-GREY SPMG-40-GREY SPMG-50-GREY SPMG-63-GREY 08
Tie Mounts K. S. TERMINALS INC. 1 SPTM、SPTMC Series SPTM-20 SPTM-25 SPTM-30 SPTM-40 SPTMA-1 SPTMA-2 SPTMC-1 SPTMC-2 09
Cable Clips K. S. TERMINALS INC. 1 SPNCR Series SPNCR-3MM SPNCR-3.5MM SPNCR-4MM SPNCR-5MM SPNCR-6MM SPNCR-7MM SPNCR-8MM SPNCR-9MM SPNCR-10MM SPNCR-12MM SPNCR-14MM SPNCR-16MM SPNCR-17MM SPNCR-18MM SPNCR-20MM SPNCR-22MM SPNCR-25MM SPNCR-30MM SPNCR-32MM SPNCR-35MM SPNCR-40MM SPNCR-50MM 10
Cable Clips K. S. TERMINALS INC. 2 SPNCK Series SPNCK-4MM SPNCK-5MM SPNCK-6MM SPNCK-7MM SPNCK-8MM SPNCK-9MM SPNCK-10MM SPNCK-12MM SPNCK-14MM SPNCK-16MM SPNCK-22MM SPNCK-25MM 10
R-type Cable Clamps K. S. TERMINALS INC. 1 SPCLS Series Color White Black SPCLS-1/8 SPCLS-3/16 SPCLS-1/4 SPCLS-5/16 SPCLS-3/8 SPCLS-1/2 SPCLS-5/8 SPCLS-3/4 SPCLS-1 SPCLS-1/8-BK SPCLS-3/16-BK SPCLS-1/4-BK SPCLS-5/16-BK SPCLS-3/8-BK SPCLS-1/2-BK SPCLS-5/8-BK SPCLS-3/4-BK SPCLS-1-BK 11
Heat Shrink Tubings K. S. TERMINALS INC. 1 SPHST Series Halogen-free environmentally friendly thin-walled flame-retardant heat shrinkable tube A thin-walled, soft, low-smoke, halogen-free, flame-retardant polyolefin heat-shrinkable tube, suitable for insulation protection of wires, wiring harnesses, electronic components, part number identification, mechanical protection, binding and fixing, etc. RoHS compliant Operating temperature: -40~125 ℃ Minimum full shrinkage temperature: 125 ℃ Shrink ratio: 2:1 Technical Data SPHST-GF2-0.8-BK-40 SPHST-GF2-0.8-BK-250 SPHST-GF2-1-BK-40 SPHST-GF2-1-BL-40 SPHST-GF2-1-RE-40 SPHST-GF2-1-RE-250 SPHST-GF2-1-WH-40 SPHST-GF2-1-YL-40 SPHST-GF2-2-BK-40 SPHST-GF2-2-BL-40 SPHST-GF2-2-RE-40 SPHST-GF2-2-WH-40 SPHST-GF2-2-YL-40 SPHST-GF2-3-BK-40 SPHST-GF2-3-BL-40 SPHST-GF2-3-BL-250 SPHST-GF2-3-RE-40 SPHST-GF2-3-YL-40 SPHST-GF2-5-BK-40 SPHST-GF2-5-BL-40 SPHST-GF2-5-RE-40 SPHST-GF2-5-YL-40 SPHST-GF2-5-YL-250 SPHST-GF2-6-BK-40 SPHST-GF2-6-BK-250 SPHST-GF2-6-BL-40 SPHST-GF2-6-RE-40 SPHST-GF2-6-YL-40 SPHST-GF2-9-BK-250 SPHST-GF2-9-BL-125 SPHST-GF2-9-RE-125 SPHST-GF2-9-YL-125 SPHST-GF2-12-BL-125 SPHST-GF2-12-RE-125 SPHST-GF2-12-YL-125 40 250 40 40 40 250 40 40 40 40 40 40 40 40 40 250 40 40 40 40 40 40 250 40 250 40 40 40 250 125 125 125 125 125 125 12
Vinyl Wire End Cap K. S. TERMINALS INC. 1 SPV-DR Series ( ) PVC Terminal Cover CLEAR GREEN BLACK RED BLUE SPV-DR110-20 SPV-DR110-25 SPV-DR110-30 SPV-DR187-20 SPV-DR187-25 SPV-DR187-30 SPV-DR187-32 SPV-DR187-35 SPV-DR187-40 SPV-DR187-45 SPV-DR205-25 SPV-DR205-30 SPV-DR205-35 SPV-DR205-40 SPV-DR250-25 SPV-DR250-30 SPV-DR250-32 SPV-DR250-35 SPV-DR250-40 SPV-DR250-45 SPV-DR250-50 SPV-DR10-30 SPV-DR10-40 13
Vinyl Wire End Cap K. S. TERMINALS INC. 2 SPV-DF Series DF Elbow series ( ) CLEAR GREEN BLACK RED BLUE SPV-DF110-35 SPV-DF110 SPV-DF205-35 SPV-DF187-32 SPV-DF187-35 SPV-DF250-40 13
Vinyl Wire End Cap K. S. TERMINALS INC. 3 SPV-DJ Series PVC Terminal Cover series CLEAR GREEN BLACK RED BLUE ( ) SPV-DJ211-25 SPV-DJ211-30 SPV-DJ211-35 SPV-DJ211-40 SPV-DJ221-25 SPV-DJ221-30 SPV-DJ221-32 SPV-DJ221-35 SPV-DJ221-40 SPV-DJ221-50 SPV-DJ7525 SPV-DJ7530 SPV-DJ7540 D±0.2 D1±0.2 D2±0.2 L±0.2 T±0.2 13
Vinyl Wire End Cap K. S. TERMINALS INC. 4 SPV-HHC Series PVC Terminal Cover series WHITE GREEN YELLOW RED BLUE BLACK SPV-HHC-1.25 SPV-HHC-2 SPV-HHC-3.5 SPV-HHC-5.5 SPV-HHC-8 SPV-HHC-14 SPV-HHC-22 SPV-HHC-38 SPV-HHC-60 SPV-HHC-80 SPV-HHC-100 SPV-HHC-125 SPV-HHC-150 SPV-HHC-200 SPV-HHC-250 SPV-HHC-325 ( ) 13
Vinyl Wire End Cap K. S. TERMINALS INC. 5 SPV-CS Series PVC Terminal Cover series WHITE GREEN YELLOW CLEAR RED BLUE BLACK SPV-CS-2 SPV-CS-2.5 SPV-CS-3 SPV-CS-3.5 SPV-CS-4 SPV-CS-4.5 SPV-CS-5 SPV-CS-5.5 SPV-CS-6 SPV-CS-6.35 SPV-CS-6.5 SPV-CS-7 SPV-CS-7.5 SPV-CS-8 SPV-CS-8.5 SPV-CS-9 SPV-CS-9.5 SPV-CS-10 SPV-CS-10.5 SPV-CS-11 SPV-CS-11.5 SPV-CS-12 SPV-CS-12.5 SPV-CS-13 SPV-CS-13.5 SPV-CS-14 SPV-CS-14.5 SPV-CS-15 SPV-CS-15.5 SPV-CS-16 SPV-CS-17 SPV-CS-18 SPV-CS-19 SPV-CS-20 SPV-CS-21 SPV-CS-22 SPV-CS-23 SPV-CS-24 SPV-CS-25 SPV-CS-26 SPV-CS-27 SPV-CS-28 SPV-CS-30 SPV-CS-32 SPV-CS-34 SPV-CS-36 SPV-CS-38 SPV-CS-40 SPV-CS-42 SPV-CS-44 SPV-CS-46 SPV-CS-48 SPV-CS-50 ( ) 13
SPB-AT6A系列微型斷路器是一種自動操作的電氣開關， 旨在保護電路免受過載或短路引起的過電流損壞。 其基本功能是在偵測到故障後切斷電流；它們廣泛應用於家庭、商業和工業領域。 在正常情況下，它也可用於不頻繁的開關操作。 SPB-AT6A Series miniature circuit breaker is an automatically operated electrical switch designed to protect an electrical circuit from damage caused by excess current from an overload or short circuit. Its basic function is to interrupt current flow after a fault is detected. They are common in domestic, commercial and industrial application. It also can be used for non-frequent on-and-off switching operations under normal circumstances. 我們的優勢 Our Advantage Miniature Circuit Breaker K. S. TERMINALS INC. 1 SPB-AT6A Series Tripping characteristics C Rated current up to 63A 脫扣特性 C 額定電流高達 63A Miniature Circuit Breaker according to IEC/EN 60898-1 Rated short circuit breaking capacity 6kA 1 up to 4-pole versions 符合 IEC/EN 60898-1 標準的微型斷路器 額定短路分斷能力 6kA 單極至四極型號 技術參數 Technical Data 尺寸 Dimensions 電路接線圖 Wiring Diagrams 1P 2P 4P 3P 17.6 35.2 52.8 70.4 max 84 max 77 50 81 36 45 5.5 2P 3P 1P 4P 14
Miniature Circuit Breaker K. S. TERMINALS INC. 2 SPB-AT6A Series 產品說明 Product Tips 可逆線路和負載連接 Reversible line and load connection 脫扣特性 C Tripping characteristics C 觸點位置指示視窗 Contacts position indication window 1 2 3 額定短路分斷能力 6000A Rated short circuit breaking capacity 6000A 4 5 脫扣特性 Tripping Characteristics 把手鎖的位置 The position of handle lock 14
Miniature Circuit Breaker K. S. TERMINALS INC. 3 SPB-AT6A Series 技術參數表 Technical Data 國際標準 International standard IEC/EN 60898-1 極數 Poles 1P, 2P, 3P, 4P 額定電流 Rated current 1-63A 脫扣特性 Tripping characteristics C 額定分斷能力 Rated breaking capacity I cn 6kA 額定工作電壓 Rated operational voltage Ue 230/400V AC 最低工作電壓 Minimum operational voltage Umin 12V AC 最高工作電壓 Maximum operational voltage Umax 440V AC 額定頻率 Rated frequency 50/60Hz 額定絕緣電壓 Rated insulated voltage Ui 415V AC 額定衝擊耐受電壓 Rated impulse withstand voltage Uimp 4kV 耐壓測試 Dielectric test voltage 2kV 機械壽命 Mechanical service life 10000 operation cycles 電氣壽命 Electrical service life 4000 operation cycles 線電壓連接 Line voltage connection Arbitrary above or below 安裝參數 Installation Parameters 防護等級 Degree of protection (IP) IP20, IP40 (when fitted) 操作環境溫度 Operating ambient temperature -25℃~+70℃ 端子連接類型 Terminal connection type Cable/Busbar 適用線徑範圍 Connectable conductor cross section 1-25mm2 安裝 Mounting IEC/EN 60715 top-hat rail 35mm 端子緊固力矩 Fastening torque of terminals 2-3.0N.m 污染等級 Pollution degree 2 熱元件設定基準 Reference temperature for setting of thermal element 30℃ 高度 Altitude ≤2000m 相對濕度 Relative humidity ≤95% 耐濕熱性 Resistance to humidity and heat Class 2 配件組合 Combination with Accessories 輔助觸點 Auxiliary contact Yes 警報接點 Alarm contact Yes 分勵脫扣器 Shunt release Yes 分勵跳脫裝置 + 輔助接點 Shunt release + Aux Yes 欠壓脫扣器 Undervoltage release Yes 過電壓脫扣器 Overvoltage release Yes 過欠壓脫扣器 Over & under voltage release Yes 電氣特性 Electrical Features 14
Miniature Circuit Breaker K. S. TERMINALS INC. 4 SPB-AT6A Series SPB-AT6A1PC6 產品料號 Item No. 分斷能力 Breaking capacity 極數 Poles 跳脫曲線 Tripping curve 額定電流 Rated current 6KA 1 C 6A SPB-AT6A1PC10 6KA 1 C 10A SPB-AT6A1PC16 6KA 1 C 16A SPB-AT6A1PC20 6KA 1 C 20A SPB-AT6A1PC25 6KA 1 C 25A SPB-AT6A1PC32 6KA 1 C 32A SPB-AT6A1PC40 6KA 1 C 40A SPB-AT6A1PC50 6KA 1 C 50A SPB-AT6A1PC63 6KA 1 C 63A SPB-AT6A2PC6 6KA 2 C 6A SPB-AT6A2PC10 6KA 2 C 10A SPB-AT6A2PC16 6KA 2 C 16A SPB-AT6A2PC20 6KA 2 C 20A SPB-AT6A2PC25 6KA 2 C 25A SPB-AT6A2PC32 6KA 2 C 32A SPB-AT6A2PC40 6KA 2 C 40A SPB-AT6A2PC50 6KA 2 C 50A SPB-AT6A2PC63 6KA 2 C 63A SPB-AT6A3PC6 6KA 3 C 6A SPB-AT6A3PC10 6KA 3 C 10A SPB-AT6A3PC16 6KA 3 C 16A SPB-AT6A3PC20 6KA 3 C 20A SPB-AT6A3PC25 6KA 3 C 25A SPB-AT6A3PC32 6KA 3 C 32A SPB-AT6A3PC40 6KA 3 C 40A SPB-AT6A3PC50 6KA 3 C 50A SPB-AT6A3PC63 6KA 3 C 63A SPB-AT6A4PC6 6KA 4 C 6A SPB-AT6A4PC10 6KA 4 C 10A SPB-AT6A4PC16 6KA 4 C 16A SPB-AT6A4PC20 6KA 4 C 20A SPB-AT6A4PC25 6KA 4 C 25A SPB-AT6A4PC32 6KA 4 C 32A SPB-AT6A4PC40 6KA 4 C 40A SPB-AT6A4PC50 6KA 4 C 50A SPB-AT6A4PC63 6KA 4 C 63A 14
Moulded Case Circuit Breaker K. S. TERMINALS INC. 1 SPB-EMN Series Model IEC/EN 60947-2 Poles 3P Certification Electrical Specifiction Rated Frame Level Current Inm(A) 63 125 250 Rated Current(A) ln 16,20,25,32,40,50,63 16,20,25,32,40,50,63,70, 80,100,125 100,125,160,175,200,225,250 Rated Insulated Voltage Ui(AC V) 500 690 690 Rated Impulse Withstand Voltage Uimp(V) 6000 8000 8000 Rated Working Voltage Ue(AC V) 400/415V 400/415V 400/415V Rated Limited Short-circuit Breaking Capacity lcu(kA) BreakingType N N N 220/230V(kA) 25 28 43 380/415V(kA) 20 25 35 480/500V(kA) 10 15 15 660/690V(kA) 8 10 10 DC 250V 10 15 10 Rated Working Short-circuit Breaking Capacity Ics V %lcu 75 75 75 Insolation Insolation ■ Service Life (O-C) Mechanical Standard Value 10000 10000 8500 Electrical Standard Value 2000 2000 1500 Control And indication Control model Manual Direct (RHD) □ Extended (ERH) □ Electric (MOD) □ Shunt Release(SHT) □ Undervoltage Release(UVT) □ Auxiliary Contact(AUX) □ Alarm Contact(ALT) □ Connection And lnstallation protection degree Wiring ALL Side IP40 Wiring Terminal IP20 Wiring Assembly Front/Rear Front/Rear Front/Rear Plug-in Assembly □ □ □ Draw-out Assembly - - - Arcing Distance(mm) 0, 50 ■Standard Configuration SPB-EMN63A3Pxx 2P, 3P 3P SPB-EMN125A2P/3Pxx xx: Input rated current, for example, 50 amps, product part number SPB-EMN63A3P50 SPB-EMN250A3Pxx 15
Moulded Case Circuit Breaker K. S. TERMINALS INC. 2 SPB-EMN Series xx: Input rated current, for example, 300 amps, product part number SPB-EMN400A3P300 400 630 800 225,250,275,300,315,350,400 400,500,630 630,700,800 690 690 690 8000 8000 8000 400/415V 400/415V 400/415V N N N 43 43 43 35 35 35 25 25 25 10 10 20 - - - 75 75 75 - 5000 4000 3000 1000 1000 500 □ □ □ □ □ □ □ IP40 IP20 Front/Rear Front/Rear Front/Rear □ □ □ - - - 0, 50 0, 100 3P 3P 3P SPB-EMN400A3Pxx SPB-EMN630A3Pxx SPB-EMN800A3Pxx ■Standard Configuration 15
Terminal Blocks K. S. TERMINALS INC. 1 TC Series TC-602 TC-603 TC-604 TC-605 TC-1005 TC-1004 TC-1003 TC-1002 TC-2003 TC-1505 TC-1504 TC-1503 16
Terminal Blocks K. S. TERMINALS INC. 2 TC、TB Series TC-2004 TC-2005 TC-3004 TC-3003 TC-6004 TC-6003 TC-4004 TC-4003 TB-1503 TB-1504 TB-1505 TB-1506 TB-2504 TB-2503 TB-1512 TB-1510 16
Terminal Blocks K. S. TERMINALS INC. 3 TB Series TB-3512 TB-3506 TB-3504 TB-3503 TB-2505 TB-2506 TB-2512 TB-2510 TB-4506 TB-4505 TB-4504 TB-4503 TB-100A/3P/4P 6P/12P TB-60A/4P 6P/12P TB-60A/3P TB-4512 16
Terminal Blocks K. S. TERMINALS INC. 4 TK Series TBD Series TK-010 TK-020 TK-030 TK-040 TK-060 TK-0100 TBD-10A TBD-20A 16
TBC-10A Terminal Blocks K. S. TERMINALS INC. 1 TBC Series TBC-20A TBC-30A TBC-60A TBC-100A TBC-200A TBR-10A TBR-20A TBR-60A TBR-100A TBR-30A TBR-200A TBR Series 17
Terminal Blocks K. S. TERMINALS INC. 2 IN Series IN-12BK IN-13BK IN-20BK IN-30BK IN-411S IN-60BK IN-100K IN-200K IN-400K 17
Quick Connect Terminal K. S. TERMINALS INC. 1 CMK Series CMK-412 CMK-413 CMK-414 CMK-415 CMK-412 CMK-413 CMK-414 CMK-415 CMK-412 CMK-414 CMK-413 CMK-415 18
K. S. TERMINALS INC. 2 UKK Series Quick Connect Terminal UKK-80A UKK-125A UKK-160A UKK-250A UKK-400A UKK-500A UKK-80A UKK-125A UKK-160A UKK-250A UKK-400A UKK-500A 18
LED Indicators K. S. TERMINALS INC. 1 SPIL Series AC/DC 24V Working Environment Working environment temperature: -25(40)℃ ～ +55(70)℃ Altitude: ≤ 2000 m Relative air humidity: ≤ 90% Pollution degree: Class 3 Protection degree: IP40 / IP65 LED light source (service life): > 30000H 19
LED Indicators K. S. TERMINALS INC. 2 SPIL Series Low power consumption,ultra-high brightness With discharge and anti-interference capabilities High-transparency lamp cap Durable and resistant to scratches Soft light cover Avoid dazzling lights Fasteners with ears are better for force-bearing installation The LED light-emitting chip is highly bright and durable The stable output from the ventilation and heat dissipation holes is more reassuring The dust cover reduces dust from entering Rubber gasket Alleviate vibration and enhance sealing Part NO. Voltage (AC/DC) Color SPIL-22DSG-R-24 24V SPIL-22DSG-G-24 24V SPIL-22DSG-Y-24 24V SPIL-22DSG-B-24 24V SPIL-22DSG-W-24 24V Red Green Yellow Blue White 19
No.8 Zhangbin E. 3rd Road, Xianxi Township, Changhua County 507, Taiwan (R.O.C.) TEL: +886-4-7580001 FAX: +886-4-7580003 K. S. TERMINALS INC. www.ksterminals.com
