車用線束含膠熱縮套管
操作溫度範圍 Operating temperature range
操作溫度 : -55˚C~130˚C
最低收縮溫度 : 110˚C
最低完全收縮溫度 : 135˚C
High shrink ratio semirigid polyolefin tubing
HST-AU
特性 Characteristics
4:1 高倍收縮
優異的完全密封防水性能
半硬耐磨阻燃材質
Operating temperature : -55℃ ~ 130℃
Minimum shrink temperature : 110℃
Minimum fully recovery temperature : 135℃
High shrink ratio 4:1
Absolutely seal and water proof
Semi-rigid flame retardant and abrasion resistance.
應用 Applications
AIS-ES汽車線束防水熱縮套管，專為汽車工業電子元件、線束絕緣保護及防水所設計，有較高的4:1收縮比配合耐高溫的聚醯胺熱熔膠(Polyamide)，
能對水分做充分阻隔保護線束必免受腐蝕及受潮，外壁為半硬耐磨材質聚烯烴，對於汽車嚴格的環境提供充分的保護。
顏色 Color
技術性能 Technical Data
標準顏色: 黑
擴張強度 Tensile strength
特性 Property
測試方法 Test Method
結果 Typical Value
Specifically designed to insulate, seal and protect wire splices, terminations and components in automotive industrial. High shrink ratio
4:1 and high temperature resistant Polymaide adhesive liner can be against water, moisture and corrosion. Sem-rigid outer wall provides
excellent abrasion protection and strain relief for strict environment requirement.
Standard color ：black
斷裂伸長率 Elongation at break
阻燃性 Flammability
銅腐蝕性 Copper corrosion(158℃, 168hrs.)
體積電阻率 Volume resistance
ASTM D 2671
ASTM D 2671
SAE-AMS-DTL-23053/5
UL224
ASTM D 876
縱向收縮率 Longitudinal shrinkage
UL224
老化斷裂伸長率 Elongation at break after
ASTM D 2671
aging 158℃,168 hrs.
10.4MPa (min.)
軟化溫度 Softening point
熱熔膠 Thermoplastic Adhesive
ASTM D E28
105℃
200% (min.)
0 to -10%
冷彎曲 Cold bend(-40℃, 1hrs.)
ASTM D 2671
絕緣耐壓 Dielectric voltage withstand and breakdown
2500V, 60sec, ASTM D 2671
No cracking
熱衝擊 Heat shock(250℃, 4hrs.)
ASTM D 2671
No cracking, no dropping
No breakdown
Self extinguish in 30 sec.
Pass
吸水率Water absorption
ASTM D 570
< 0.5%
老化擴張強度 Tensile strength after
ASTM D 2671
aging 158℃,168 hrs.
Remains 70%
100% (min.)
10 Ω cm (min.)
14
Adhesive-Lined Polyolefin Tubing
