通用型中壁不含膠熱收縮套管
操作溫度範圍 Operating temperature range
操作溫度 : -55˚C~110˚C
最低收縮溫度 : 80˚C
最低完全收縮溫度 : 120˚C
Medium wall tubing without hot melt adhesive
Thin Wall Polyolefin Tubing
HST-GG
特性 Characteristics
收縮率: 3:1
可以應用於不規則的連接上
能抵抗UV
良好的電氣絕緣性能
Operating temperature : -55℃ ~ 110℃
Minimum shrink temperature : 80℃
Minimum fully recovery temperature : 120℃
shrinkable ratio: 3:1
Easily fit over irregular shape and large connectors
Resistant to UV
Excellent electrical insulation
應用 Applications
大的擴張倍率提供了良好的絕緣和保護電纜連接和終端的性能，另外高抗磨性能和抗腐蝕性能可以很好的應用於通信電纜和管道。
顏色 Color
技術性能 Technical Data
標準顏色: 黑
特性 Property
測試方法 Test Method
結果 Typical Value
High shrink ratio which provide excellent properties of insulation and protection to cable joints and terminations.
And high abrasion and corrosion resistance for applying in communication cable and chemical pipe.
Standard color ：black
斷裂伸長率 Elongation at break
銅穩定性 Copper stability
壓力破裂抵抗性 Resistance to stress cracking(50℃)
體積電阻率 Volume resistance
ASTM D 2671
ASTM D 2671
ASTM D 1693
IEC 93
縱向收縮率 Longitudinal shrinkage
UL224
老化斷裂伸長率 Elongation at break after aging
150℃, 168 hrs.
擴張強度 Tensile strength
ASTM D 2671
≧ 14MPa
≧ 400%
密度 Density
ASTM D 792
1.05g/cm
0 to -10%
絕緣強度 Dielectric strength
IEC 243
偏壁率 Eccentricity
ASTM D 2671
< 30%
≧ 20KV/mm
Pass
No cracking
吸水率Water absorption
ISO 62
< 0.15%
≧ 300%
≧ 10 Ω cm
14
3
