汽車線束用捲式編織管
操作溫度範圍 Operating temperature range
操作溫度 : -40˚C~125˚C (非阻燃)
-40˚C~150˚C (阻燃)
wraparound braided sleeving for automotive wire assembly
Braided Sleeving
KBS-CF / KBS-CN
特性 Characteristics
阻燃
抗紫外線、柔軟
對大部分的化學和溶解性物質有抵抗性
高耐磨擦性能
優異的降噪音功能
Operating temperature : -40℃ ~ 125℃ (Non-flame retardant)
-40˚C~150˚C (Flame retardant)
Non-flame
retardant
Flame
retardant
Flame retardant
UV resistance, flexible
Not affected by most chemicals and solvents
Excellent abrasion property
Outstanding noise reduction
應用 Applications
由單絲和多絲纖維聚酯編織而成，剖開捲式設計，方便快速將線組集線施工，並可以方便在兩端封閉狀況下安裝和缷載，極為柔軟的
材質提供抗磨損保護及良好的避震和吸音作用，可以做取代波紋管(浪管)的功能。
顏色 Color
技術性能 Technical Data
標準顏色: 黑
Designed from monofilament and multifilament polyester yarns. The unique split and self-closes construction makes it quick
and easily to wrap around a group of wires. Very convenient to install and remove from a completed assemblies.
Flexible material provides abrasion resistance as well as diminish noise and vibration, can instead of slit loom and spiral wrap.
Standard color ：black
特性 Property
測試方法 Test Method
結果 Typical Value
熔解溫度 Melt temperature
ASTM D 2117
低溫柔軟性 Low temperature flexibility
MIL 123053/5
250
˚C
耐溫(非阻燃) Temperature rating(Non-flame retardant)
125
˚C / 240hrs
pass
-40
˚C
單絲伸長率 Monofilament Elongation
ASTM D 2256
15-31%
多絲伸長率 Multifilament Elongation
ASTM D 2256
35-44%
耐溫 Temperature rating
150
˚C / 240hrs
pass
