產品規格 Product Dimensions
產品型號
Part Number
尺寸
Nominal Size
收縮前尺寸 (米釐)
As supplied (mm)
內徑(最小值)
I.D. (min.)
米釐
mm
英吋
inch
HST-HV1.2-BK
KST-HV1.2-CL
1.2
1.2
0.6
0.25±0.05
1.2
HST-HV1.6-BK
HST-HV1.6-CL
1.6
1.6
0.8
0.25±0.05
1.2
1312-0311
1312-0312
1312-0313
1312-0314
3/64
1/16
HST-HV2.4-BK
KST-HV2.4-CL
2.4
2.4
1.2
0.25±0.05
1.2
HST-HV3.2-BK
HST-HV3.2-CL
3.2
3.2
1.6
0.25±0.05
1.2
1312-0315
1312-0316
1312-0317
1312-0318
3/32
1/8
HST-HV19-BK
KST-HV19-CL
19.1
19.1
9.5
0.43±0.08
1.2
HST-HV25-BK
HST-HV25-CL
25.4
25.4
12.7
0.48±0.08
1.2
1312-0327
1312-0328
1312-0329
1312-0330
3/4
1
HST-HV38-BK
KST-HV38-CL
38.1
38.1
19
0.51±0.08
1.2
HST-HV50-BK
HST-HV50-CL
50.8
50.8
25.4
0.58±0.08
1.2
1312-0331
1312-0332
1312-0333
1312-0334
1 1/2
2
HST-HV4.8-BK
KST-HV4.8-CL
4.8
4.8
2.4
0.25±0.05
1.2
HST-HV6.4-BK
HST-HV6.4-CL
6.4
6.4
3.2
0.30±0.08
1.2
1312-0319
1312-0320
1312-0321
1312-0322
3/16
1/4
HST-HV9.5-BK
KST-HV9.5-CL
9.5
9.5
4.8
0.30±0.08
1.2
HST-HV12-BK
HST-HV12-CL
12.7
12.7
6.4
0.30±0.08
1.2
1312-0323
1312-0324
1312-0325
1312-0326
3/8
1/2
內徑(最大值)
I.D. (max.)
壁厚
W.T.
收縮後尺寸 (米釐)
After recovered (mm)
標準長度 (米)
Standard Length (M)
製造料號
MFG P/N
High Temperature Heat Shrinkable Tube
