PET剖開捲式編織管
操作溫度範圍 Operating temperature range
操作溫度 : -40˚C~125˚C
Semi-rigid wrappable split braided sleeving
KBS-SR
特性 Characteristics
抗紫外線
對大部分的化學和溶解性物質有抵抗性
PET材質具有很好的耐用性
優異的抗磨擦性能
Operating temperature : -40℃ ~ 125℃
UV light resistant polyester yarn
Not affected by most chemicals and solvents
PET material has excellent durability property
Excellent abrasion and cut-through resistance
應用 Applications
由PET單絲編織而成，剖開捲式設計方便施工及應用在不規格的形狀並可以很方便在雙端封閉的場合安裝和缷除，可以做取代波紋管(浪管)的功能。
顏色 Color
技術性能 Technical Data
標準顏色: 黑
Designed from PET monofilament yarns, unique construction and split makes it simply self-closes around a group of wires.
It s flexible and lightweight enough to bend to a tight radius without distorting and splitting for allowing coverage around inline plugs,
connectors and splices without the need for any additional fasteners (Velcro, tape, etc.), which can instead of slit loom and spiral wrap.
Standard color ：black
特性 Property
測試方法 Test Method
結果 Typical Value
比重 Specific gravity
抗菌性 Fungus resistance
銅腐蝕性 Copper corrosivity
彎曲係數 Flexural modulus
ASTM D-876
MIL STD 810 (508)
MIL I 23053
ASTM D-790
吸濕性 Moisture absorption(24 hours)
ASTM D-570
1.31
伸長率 Elongation
ASTM D-876
20%
0.08%
熔解溫度 Melt temperature
ASTM D-2117
低溫柔軟性 Low temperature flexibility
MIL I 23053/5
250
˚C
最大操作溫度 Max. operating temperature
UL224
125
˚C
-70
˚C
不滋生 No Growth
不影響 No effect
400
拉伸強度 Tensile strength
ASTM D-876
100,000 psi
‘
Braided Sleeving
產品規格 Product Dimensions
產品型號
Part Number
尺寸
Nominal Size
張開寬度(米釐)
Opening expansion width (mm)
公尺/每卷
Mater/Roll
英呎/每卷
Feet/Roll
包裝
Packing
KBS-SR3.2
3.2
1/8”
23±4
100’
1313-0019
製造料號
MFG P/N
米釐
mm
英吋
inch
KBS-SR6.4
6.4
1/4”
45±4
100’
1313-0020
KBS-SR12
12.7
1/2”
60±4
75’
1313-0021
KBS-SR19
19.1
3/4”
89±4
50’
1313-0022
KBS-SR25
25.4
1”
110±4
25’
1313-0023
KBS-SR38
38.1
1-1/2”
150±4
25’
1313-0024
KBS-SR50
50.8
2”
205±5
25’
30.5
30.5
22.8
15.2
7.6
7.6
7.6
1313-0025
